It could be widely used in the oil monitoring of all kinds of vehicles, also could be combined with the communication technology of GPS/GPRS and via computer software management platform to achieve scientific management of vehicle and then to prevent oil theft and be saving the vehicle operating cost.
Features:
1) Measuring precision, measurement resolution is 0.1mm, liquid level measurement accuracy is 0.5%.
2) Good stability; 3) Easy to install; 4) Simple application; 5) Strong antistatic ability (EMC);
6) Variety of standard signal output ways, which are analog voltage (1-5V) and current (4-20mA), digital output RS232 and RS485;
Technical parameters:
Ultrasonic liquid level detector | ||
Operating Voltage |
DC9V-36V |
|
The power supply ripple |
Less than 100mV |
|
Operating current |
Less than 55mA |
|
Measuring distance |
4cm to 100cm; pressure-bearing range: -0.1MPa~32MPa |
|
Resolution |
0.1mm |
|
Measurement accuracy |
0.5% |
|
Temperature compensation range |
-40 - +80°C |
|
Output mode |
analog voltage,current,RS485,RS232 |
|
Analog output |
Voltage output (default) |
1-5V (corresponding 0-100cm) |
Current output |
4-20mA (corresponding 0-100cm) |
|
Digital output |
RS232(default) |
See the “communication protocol” |
RS485 | ||
Alarm output |
need external connection a alarming horn to achieve alarm |
|
Install method |
bottom of fuel tank/can, water tank |
|
Operating temperature |
-40 - +80°C |
|
Storage temperature |
-50 - +100°C |
|
Size |
102*84*25mm with mounting holes |
|
Ultrasonic transducer | ||
Operating temperature |
-40 - +80°C |
|
IP grade |
IP66 |
|
Cable length |
8m and with shield |
|
Weight |
About 770g |
|
|
Notice: 1) If no any requirement we’ll delivery the goods to you as the default output mode: analog output: 1-5V + digital output: RS232; If you need other output modes please advise us in advance; 2) The liquid measure is default as the diesel,the distance of the internal output is calculated by the propagation velocity of voice in the diesel. If you want to measure other liquid please advise us in advance; 3) The measurement accuracy is 0.5%, which is based on the liquid and the liquid level is calm without shaking, the material of fuel tank is iron, for the measuring accuracy which has 0-5mm deviation as different material and thickness of fuel tank; The measurement distance is based on the material and thickness of tank, the default testing tank is aluminum material and the thickness is 5.5mm; If test the Iron plate and stainless steel, the real distance will be about 80cm; If the thickness of tank is more than 5.5mm please also advise us in advance before purchasing; | ||
