Home > Products > Ultrasonic Fuel Capacity Sensor > Non contact ultrasonic level sensorUltrasonic sensoAnti theft ultrasonic level meter for oil water fuel diesel level measurement
Non contact ultrasonic level sensorUltrasonic sensoAnti theft ultrasonic level meter for oil water fuel diesel level measurement
- 20000 Set / Sets per Month
- shenzhen
- Credit Card
Product Details
Place of Origin: | Guangdong, China | Brand Name: | Dianyingpu | Model Number: | DS1309 |
Product Description
It could be widely used in the oil monitoring of all kinds of vehicles, also could be combined with the communication technology of GPS/GPRS and via computer software management platform to achieve scientific management of vehicle and then to prevent oil theft and be saving the vehicle operating cost.
Features:
1)Measuring precision, measurement resolution is 0.1mm, liquid level measurement accuracy is 1mm.
2) Good stability; 3) Easy to install; 4) Simple application; 5) Strong antistatic ability (EMC);
6) Variety of standard signal output ways, which are analog voltage (1-5V) and current (4-20mA), digital output RS232 and RS485;
Technical parameters:
Ultrasonic liquid level detector | ||
Operating Voltage | DC9V-36V | |
The power supply ripple | Less than 100mV | |
Operating current | Less than 55mA | |
Measuring distance | 4cm to 100cm; pressure-bearing range: -0.1MPa~32MPa | |
Resolution | 0.1mm | |
Measurement accuracy | 0.5% | |
Temperature compensation range | -40 - +80°C | |
Output mode | analog voltage,current,RS485,RS232 | |
Analog output | Voltage output (default) | 1-5V (corresponding 0-100cm) |
Current output | 4-20mA (corresponding 0-100cm) | |
Digital output | RS232(default) | See the “communication protocol” |
RS485 | ||
Alarm output | need external connection a alarming horn to achieve alarm | |
Install method | bottom of fuel tank/can, water tank | |
Operating temperature | -40 - +80°C | |
Storage temperature | -50 - +100°C | |
Size | 102*48*25mm with mounting holes | |
Ultrasonic transducer | ||
Operating temperature | -40 - +80°C | |
IP grade | IP66 | |
Cable length | 8m and with shield | |
Weight | About 770g |
