High Measurement Accuracy Ultrasonic Distance Measuring ModuleDistance SensorHigh Sound Pressure Output Ultrasonic Sensor Module

Features:

1) High sound pressure output;

2) Power supply: 5V;

3) Current: less than 20mA;

4) UART auto-output;

5) PWM controlled output;

6) Digital output;

7) Transmission-receiving enclosed sensor with long cable;

8) Center frequency: 40KHz;

9) Temperature compensation;

10) Working temperature: -15 degree centigrade to +60 degree centigrade;

11) Storage temperature: -25 degree centigrade to +80 degree centigrade;

12) Measurement accuracy: +/-1cm + (S*0.3%) (S is measured value);

13) Electrostatic protective design, the enclosure of sensor and the I/O pin are added the electrostatic protection device, up to

the standard of IEC61000-4-2;

Advantage:

1) High degree of protection;

2) Strong anti-interference;

3) Data output, stable and reliable;

4) Lower power dissipation;

5) Fast response time;

6) Strong antistatic;

7) Wide working temperature;

8) High measurement accuracy;

9) Small bulk and easy to install;

10) Auto-output distance value, release the processor of user;

11) With controlled output mode, could minimize power consumption according to the actual application;

There are three output modes: PWM, UART

and digital output, which corresponding item number are:

DYP-ME007YS-PWM V1.0

DYP-ME007YS-TX V1.0

DYP-ME007YS-KG V1.0

Please kindly advise which output mode you needed before purchasing order (our default output mode is PWM).
