Wide Range Ultrasonic SensorsUltrasonic Sensor DistanceUltrasonic Distance SensorsUltrasonic Sensor for Distance Measurement
US$ 33.25 - 58.87
MOQ: 1000 Pieces
Key Specifications
Get Latest Price
Place of Origin:
Guangdong, China
Brand Name:
DYP
Model Number:
DYP-ME007Y50H V2
Payment & Shipping
Payment Methods:
Port of Shipment:
SHENZHEN
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Waterproof Non-contact Distance RangingWaterproultrasonic Distance SensorsWaterproof Ultrasonic Sensor Distance Measuring ModuleUS$ 11.28 - 15.94MOQ: 100 Sets -
Long Range Ultrasonic SensorUltrasonic Sensor ModuleUltrasonic Distance MeasurerSensorUltrasonic Sensor for Distance MeasurementUS$ 33.25 - 58.87MOQ: 1000 Pieces
-
Long Distance Ultrasonic SensorUltrasonic Sensor Distance MeterUltrasonic DetectorSenUltrasonic Distance Measuring Sensor ModuleUS$ 42.74 - 58.87MOQ: 100 Pieces
-
Ultrasonic Sensor ModuleUltrasonic Sensor DistanceWide Range Ultrasonic SensorsDetectorsUltrasonic Distance Sensor ModuleUS$ 60 - 80MOQ: 1 Piece
-
Long Distance Ultrasonic SensorUltrasonic Distance Measuring Sensor ModuleUltrasonic DetectorSensorsUltrasonic Sensor ModuleUS$ 35.67 - 58.87MOQ: 500 Pieces
Place of Origin
Guangdong, China
Brand Name
DYP
Model Number
DYP-ME007Y50H V2
Usage
Position Sensor
Theory
Ultrasonic Sensor
Output
Digital Sensor
It is based on electrostatic senscomp's 600 ultrasound transducer design. It can measure a distances of up to 8m. The angle between the ultrasound probes is only 15 °, while the majority of the ultrasound is 60 °.
Applications
- robot navigation and obstacle avoidance
- measuring distance devices
- engineering measurement tools
- industrial control system
Specification
- Power Supply: DC5V(default), DC6-12V (optional);
- Current: standbyl current is less than 10mA, when sending the instant the current is about 250mA;
- Operating temperature range: -20°C ~ + 70°C
- Interface: PWM and UART serial output (default), RS485(optional)
- Operating frequency 50KHZ. Probe direction angle 15 ° (-6dB)
- Ultrasonic Distance Measurement: 8 cm to 8 m
- Distance resolution: 0.1cm (UART serial mode)
- Operating modes: single-echo mode and multi-echo mode
