Specifications
It is a low cost ligital compass with UART and IIC interface, it's easy to use with external controler like Arduino,IFLAT32.It is a low cost ligital compass with UART and IIC interface, it's easy to use with external controler like Arduino,IFLAT32.
Command
• 0 x 31: the first angle measurement
• 0 x C0: calibration of the magnetic field start
• 0 x C1: the end of the calibration magnetic field
• 0 x A0-0XAA-0XA5-0XC5: Restore default setting
• 0 x 03 + 8bit: Setting the magnetic declination high 8 bit
• 0 x 04 + 8bit: Setting the magnetic declination low8 bit
Return Data
• Byte0: 0x0D
• Byte1: 0x0A
• Byte2: 0x30 ~ 0x33 angle of one hundred (ASCII 0 - 3)
• Byte3: 0x30 ~ 0x39 angle of ten (ASCII 0 - 9)
• Byte4: 0x30 ~ 0x39 angle a bit (ASCII 0 - 9)
• Byte5: 0x2E (ASCII code decimal point)
• Byte6: 0x30 ~ 0x39 decimal point (ASCII 0 - 9)
• Byte7: 0x00 ~ 0xFF checksum (only lower 8bit)
