Home > Electrical & Electronics > Sensor > Pressure Sensor > Compass ModuleLow-cost Difital CompassDigital GY-26 Compass Sensor Module for GPS NavigationSensorsGY-26 Compass Sensor Module

Compass ModuleLow-cost Difital CompassDigital GY-26 Compass Sensor Module for GPS NavigationSensorsGY-26 Compass Sensor Module

Compass ModuleLow-cost Difital CompassDigital GY-26 Compass Sensor Module for GPS NavigationSensorsGY-26 Compass Sensor Module thumbnail-1
Compass ModuleLow-cost Difital CompassDigital GY-26 Compass Sensor Module for GPS NavigationSensorsGY-26 Compass Sensor Module photo-1
US$ 16.58 - 19.99 MOQ: 10 Pieces
Key Specifications
Get Latest Price
Place of Origin:
Guangdong, China
Brand Name:
DYP
Model Number:
GY-26
Contact Supplier Request Quote Chat Now
Shenzhen Dianyingpu Technology Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
shenzhen
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Guangdong, China
Brand Name DYP
Model Number GY-26
Usage Other, Navigation...
Theory Other, utilizing magneto resistive sensor sensing the Earth's magnetic field
Output Digital Sensor

Specifications

It is a low cost ligital compass with UART and IIC interface, it's easy to use with external controler like Arduino,IFLAT32.

Features:

  • This is a low cost plane digital compass
  • The working principle is utilizing magneto resistive sensor sensing the Earth's magnetic field component, so as to get an azimuth angle
  • Light weight and high cost-effective
  • With stabile operation and high accuracy
  • Very low operating voltage (3 - 5V DC)
  • DC single supply operation
  • Advanced hard iron calibration
  • Size (L x W): Approx. 1 x 1 inch / 2.5 x 2.5 cm

Electrical Parameters:

  • Working Temperature: Between -20 degC and 85 degC
  • Store Temperature: Between -40 degC and 125 degC
  • Current Consumption: 5V 15mA, 3V 8mA
  • Response Frequency: 25Hz
  • Measuring Range: Between 0 degrees to 360 degrees
  • Resolution: 0.1 degree
  • Measuring Precision: 1 degree

Applications:

  • Handheld electronic instrument
  • Robot orientation and position
  • Navigation system
  • Telescope position
  • Auto helm rudder
  • Antenna position
  • Automobile GPS navigation
  • Aero model position
