Help CenterLow Voltage DC0.8V-9V PIR Infrared Motion Sensor Detect Module Sensor Switch Infrared PIR Motion SensorPIR Sensor Module
Related Products
-
Pyroelectric Infrared PIR Motion Sensor With Black Lens PIR Motion Sensor PIR Motion DetectorPyroelectric Infrared Sensor ModuleUS$ 2.14 - 4.53MOQ: 1000 Pieces -
AC220V Infrared PIR Motion Sensor Detector ModuleIntelligent SwitchIR SensorInfrared Detector ModuleIR Detector ModulePIR SensorUS$ 2.63 - 5.67MOQ: 1 Piece
-
Adjustable Human Body Infrared Motion Sensor ModuleMini Pyroelectric PIR Motion SensorTiny PIR Motion Sensor Detector ModuleUS$ 1.87 - 3.26MOQ: 500 Pieces
-
Passive Infrared Motion SensorMini IR Pyroelectric Infrared PIR Motion Human Sensor Automatic Detector ModulePIR Motion SensorsUS$ 1.79 - 3.25MOQ: 1000 Pieces
-
SensorsLow Voltage Smart PIR SensorHigh Frequency Motion Sensor ModuleMotion Sensor for LightPIR Motion Sensing Movement SensorUS$ 2.44 - 5.97MOQ: 500 Pieces
This is a pyroelectric sensor module which developed for human body detection. Features low voltage, low noise and high sensitivity, it is widely used in the intellectualized detection of human body, for lighting, motion sensor and security systems.
Features:
1 Output Modes: High and low level signal, convenient for connecting with other kinds of circuits;
2 Can Operate at Low Voltage: DC 0.8V-9V, eapecially for the electric equipments powered by aneroid battery;
3 Optional trigger methods between repeatable trigger (default) and non-repeatable trigger;
Specifications:
Operating voltage range |
DC 0.8V - 9V |
Quiescent current |
<150uA(power supply 5V), different voltage, different power consumption |
Mode of output |
Level output: high: 3.3V / low: 0V; Or NPN open collector drain output: drive current<300 mA; |
Photosensitive control |
It will not sense in daytime or in the condition of strong light;It will sense in night or in the condition of weak light |
Temperature compensation |
When the temperature is close to the human temperature,it could adjust the sensitivity automatically |
Mode of trigger |
non-repeatable trigger(default) / repeatable trigger |
Delay time |
Default:10S (could be customized in zero a few seconds to dozens of minutes); |
Blockade time |
Default as 2.5S, could be customized in zero a few seconds to a few dozen seconds |
Dimensions of the board |
28mm X 28mm |
Angle of induction |
<110°Cone angle |
Sensing distance |
within 7 m |
Operating temperature |
-20℃ - +80℃ |
Size of induction lens |
Diameter:23mm X 16mm |
