Specifications
This DS18B20 temperature sensor is designed for use in liquid media or situation in which waterproof is required.
This DS18B20 temperature sensor is designed for use in liquid media or situation in which waterproof is required. Measures approx. 3 meters in length, this temperature sensor is widely used in cold-storage room, beer production, environment monitoring, and various temperature instruments, etc.
Features:
1 Core Components: DS18B20, with high accuracy and good stability;
2 "Bus line" digital transfer, greatly improving system anti-interference;
3 Nickel-plated brass shell package, which is waterproof and corrosion-resistant;
4 Suitable for temperature measurements in liquid media;
Parameters:
1 Sensor Type: DS18B20 digital temperature sensor;
2 Operating Voltage: 3 - 5.5V;
3 Measuring Range: -55 ~ +125°C;
4 Temperature Accuracy: ± 0.5°C (-10~+85°C condition);
5 Temperature Resolution: 9-12 bit (0.0625°C);
6 Cable Length: Approx. 126 inch / 3 meters;
7 Cable Color: Black;
Pin Definition:
1 VCC - Power supply (red wire);
2 DQ - Data (white wire);
3 GND - Power ground (shielded cable);
Note:
It also could be customized as customers' requirement!!!!!
