Specifications
1) Screw material : Bimetallic Alloy Screw, SKD material Screws,Stainless Steel Screws etc2) Factory name: Jinsheng Bimetallic
Injection screw and barrel/ Injection screw
Screw and Barrel for molding injection
| Screw Diameter | OD18-OD250MM |
| Injection Capacity | 15-50000G |
| Materials |
1) 38CrMoALA(JIS SACM645) 2) 42CrMo (JIS SCM440) 3) 9Cr18MoV 5)SKD61 |
| Application |
1)General Plastics 2)ABS,PA,PC,PE,PET,PP,PS,EVA,PU,PVC,U-PVC,etc 3)PA + GF(Glass Fiber) 4)Flame-resistant Reinforced Plastics 5)Modified Engineering Plastics 6)All kinds of Mixed Recycled Material(in Scrap or Granule),etc |
| Heat Treatment |
1) High Frequency Treatment 2) Nitriding treatment 3) Hard Chrome Plating treatmen 4) Vacuum Quenching treatment 5) Bimetallic alloy coating treatment |
| Depth of Nitration | 0.5-0.8mm |
| Hardness of Nitration | 950-1020Hv |
| Fragility of Nitration | Less than grade 1 |
| Roughness of surface | Ra 0.4um |
| Linearity of screw | 0.015mm |
| Hardness of bimetallic | HRC58-62 |
| Depth of Bimetallic | 2-3mm |
| Double-alloy level |
1) Level A - containing Tungsten of 40% 2) Level B - containing tungsten of 25% 3) Level C - containing tungsten of 9.5% |
| Bimetallic Alloy Materials |
1)Fe-based alloy 2)Ni-based alloy/Deloro alloy 3)Co-based alloy 4)NiCo-based alloy 5)Tungsten carbide/Wolfram carbide |
| Packaging |
1) Film wrapped in wooden case without fumigation (export standard) 2) As customer request |
| Gurantee time | More than 1 year |
| Advantages |
1)High productivity 2)Wonderful plasticizing 3) low energy consumption 4)Wearable and Durable 5)Fast and On time delivery 6)Best customer service |
| Brand | J.S BRAND |
Injection screw and barrel picture
PACKING SHOWS:
Services:
1) Screw structure, compression ratio and material can be changed according to different products and output
2) Technological Process can be chosed acoodring to your requirments.
3) Various high quality alloy steels , According to different usage, the choose for alloy is different, some require for abrasion-resistant while some require for corrsion-resistant. For standard, we have Fe-based, Ni-based, W2C alloy,Tunsten alloy etc for choice.
4) We are able to take mapping, design for clients and make products as per customer's drawing or existing sample
If you have any question,please contact with me directly :
HAPPY-- M:86-136-46807744
