Product Details
Place of Origin: | Jiangsu, China | Model Number: | VB3 series | Output Power: | 51 - 100W |
Output Type: | Single | Input Voltage: | 220v | Type: | DC/AC Inverters |
Output Frequency: | 0.4kw | Output Current: | 3.8A |
Product Description
Specifications
Our factory is the biggest INVERTER supplier in china,our price is very competitive with good qualityVB3 series
Single phase 220V 50/60Hz | Model | Function |
VB3-20P4 | Suitable motor:0.4KW ;rated output current: 3.0A External Dimension: 50*127*165mm | |
VB3-20P7 | Suitable motor: 0.75KW; rated output current: 4.7A External Dimension: 50*127*165mm |
Three phases 380V 50/60Hz | Model | Function |
VB3-40P7 | Suitable motor: 0.75KW; rated output current: 2.5A External dimension: 80*200*162mm | |
VB3-41P5 | Suitable motor: 1.5KW rated output current: 4.5A External dimension: 80*200*162mm | |
VB3-42P2 | Suitable motor: 2.2KW Rated output current:6.0A External Dimension: 80*200*162mm | |
VB3-43P7 | Suitable motor: 3.7KW; rated output current: 9.6A External dimension: 80*200*162mm |
Note:
VB3 is compact size, don't support brake unit and X6 terminal.
The operation panel is un-extensible.
VB5 series
Single phase 220V 50/60Hz | Model | Function |
VB5-20P7 | Suitable motor: 0.75KW; rated output current: 4.7A;External Dimension: 70*170*162mm | |
VB5-21P5 | Suitable motor: 1.5KW; rated output current: 7.5A; External Dimension: 70*170*162mm | |
VB5-22P2 | Suitable motor: 2.2KW; rated output current: 10A;External Dimension: 70*170*162mm |
Three phases 380V 50/60Hz | Model | Function |
VB5-41P5 | Suitable motor: 1.5KW; rated output current: 4.5A;External dimension: 80*200*162mm | |
VB5-42P2 | Suitable motor: 2.2K;rated output current:6.0A; External dimension: 80*200*162mm | |
VB5-43P7 | Suitable motor :3.7KW;Rated output current:9.6A;External Dimension: 80*200*162mm |
V5 series
Three phases 380V 50/60Hz | Model | Function |
V5-45P5 | Suitable motor: 5.5KW; rated output current: 14A;External Dimension: 220*300*210mm | |
V5-47P5 | Suitable motor: 7.5KW; rated output current: 17A;External Dimension: 220*300*210mm | |
V5-4011 | Suitable motor: 11KW; rated output current: 25A; External Dimension: 230*420*217.6mm | |
V5-4015 | Suitable motor:15KW; rated output current: 32A;External Dimension: 230*420*217.6mm | |
V5-4018 | Suitable motor:18.5KW; rated output current: 37A;External Dimension: 230*420*217.6mm | |
V5-4022 | Suitable motor:22KW; rated output current: 45A; External Dimension: 290*450*217mm | |
V5-4030 | Suitable motor:30KW; rated output current: 60A; External Dimension: 290*450*217mm | |
V5-4037 | Suitable motor:37KW; rated output current: 75A; External Dimension: 375*581*261mm |
