ALL CATEGORIES

FREQUENCY INVERTER

Negotiable MOQ: 5 Sets (Price negotiable depending on order volume and customization)

Key Specifications

Place of Origin:

Jiangsu, China

Model Number:

VB3

Wuxi Lotus Import And Export Company Limited

Payment & Shipping

Payment Methods:

Port of Shipment:

shanghai

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Jiangsu, China

Model Number VB3

Specifications

Our factory is the biggest INVERTER supplier in china,our price is very competitive with good quality

Inverter

Single phase 220V 50/60Hz	Model	Function
	VB3-20P4	Suitable motor:0.4KW ;rated output current: 3.0A External Dimension: 50127165mm
	VB3-20P7	Suitable motor: 0.75KW; rated output current: 4.7A External Dimension: 50127165mm

Three phases 380V 50/60Hz	Model	Function
	VB3-40P7	Suitable motor: 0.75KW; rated output current: 2.5A External dimension: 80200162mm
	VB3-41P5	Suitable motor: 1.5KW rated output current: 4.5A External dimension: 80200162mm
	VB3-42P2	Suitable motor: 2.2KW Rated output current:6.0A External Dimension: 80200162mm
	VB3-43P7	Suitable motor: 3.7KW; rated output current: 9.6A External dimension: 80200162mm

Note:

VB3 is compact size, don't support brake unit and X6 terminal.

The operation panel is un-extensible.

Single phase 220V 50/60Hz	Model	Function
	VB5-20P7	Suitable motor: 0.75KW; rated output current: 4.7A;External Dimension: 70170162mm
	VB5-21P5	Suitable motor: 1.5KW; rated output current: 7.5A; External Dimension: 70170162mm
	VB5-22P2	Suitable motor: 2.2KW; rated output current: 10A;External Dimension: 70170162mm

Three phases 380V 50/60Hz	Model	Function
	VB5-41P5	Suitable motor: 1.5KW; rated output current: 4.5A;External dimension: 80200162mm
	VB5-42P2	Suitable motor: 2.2K;rated output current:6.0A; External dimension: 80200162mm
	VB5-43P7	Suitable motor :3.7KW;Rated output current:9.6A;External Dimension: 80200162mm

Three phases 380V 50/60Hz	Model	Function
	V5-45P5	Suitable motor: 5.5KW; rated output current: 14A;External Dimension: 220300210mm
	V5-47P5	Suitable motor: 7.5KW; rated output current: 17A;External Dimension: 220300210mm
	V5-4011	Suitable motor: 11KW; rated output current: 25A; External Dimension: 230420217.6mm
	V5-4015	Suitable motor:15KW; rated output current: 32A;External Dimension: 230420217.6mm
	V5-4018	Suitable motor:18.5KW; rated output current: 37A;External Dimension: 230420217.6mm
	V5-4022	Suitable motor:22KW; rated output current: 45A; External Dimension: 290450217mm
	V5-4030	Suitable motor:30KW; rated output current: 60A; External Dimension: 290450217mm
	V5-4037	Suitable motor:37KW; rated output current: 75A; External Dimension: 375581261mm
