FREQUENCY INVERTER

FREQUENCY INVERTER thumbnail-1
FREQUENCY INVERTER photo-1
Negotiable MOQ: 5 Sets (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Place of Origin:
Jiangsu, China
Model Number:
VB3 series
Output Power:
51 - 100W
Contact Supplier Request Quote Chat Now
Wuxi Lotus Import And Export Company Limited
Payment & Shipping
Payment Methods:
Port of Shipment:
shanghai
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Jiangsu, China
Model Number VB3 series
Output Power 51 - 100W
Output Type Single
Output Voltage 220v
Type DC/DC Converters
Output Frequency 50hz
Output Current 3a

Specifications

Our factory is the biggest INVERTER supplier in china,our price is very competitive with good quality

Inverter

VB3 series



Single phase 220V 50/60Hz

Model

Function

VB3-20P4

Suitable motor:0.4KW ;rated output current: 3.0A External Dimension: 50*127*165mm

VB3-20P7

Suitable motor: 0.75KW; rated output current: 4.7A External Dimension: 50*127*165mm



Three phases 380V 50/60Hz

Model

Function

VB3-40P7

Suitable motor: 0.75KW; rated output current: 2.5A External dimension: 80*200*162mm

VB3-41P5

Suitable motor: 1.5KW rated output current: 4.5A

External dimension: 80*200*162mm

VB3-42P2

Suitable motor: 2.2KW Rated output current:6.0A External Dimension: 80*200*162mm

VB3-43P7

Suitable motor: 3.7KW; rated output current: 9.6A External dimension: 80*200*162mm





Note:

 VB3 is compact size, don't support brake unit and X6 terminal.

The operation panel is un-extensible.



VB5 series



Single phase 220V 50/60Hz

Model

Function

VB5-20P7

Suitable motor: 0.75KW; rated output current: 4.7A;External Dimension: 70*170*162mm

VB5-21P5

Suitable motor: 1.5KW; rated output current: 7.5A; External Dimension: 70*170*162mm

VB5-22P2

Suitable motor: 2.2KW; rated output current: 10A;External Dimension: 70*170*162mm



Three phases 380V 50/60Hz

Model

Function

VB5-41P5

Suitable motor: 1.5KW; rated output current: 4.5A;External dimension: 80*200*162mm

VB5-42P2

Suitable motor: 2.2K;rated output current:6.0A;

External dimension: 80*200*162mm

VB5-43P7

Suitable motor :3.7KW;Rated output current:9.6A;External Dimension: 80*200*162mm



V5 series



Three phases 380V 50/60Hz

Model

Function

V5-45P5

Suitable motor: 5.5KW; rated output current: 14A;External Dimension: 220*300*210mm

V5-47P5

Suitable motor: 7.5KW; rated output current: 17A;External Dimension: 220*300*210mm

V5-4011

Suitable motor: 11KW; rated output current: 25A;

External Dimension: 230*420*217.6mm

V5-4015

Suitable motor:15KW; rated output current: 32A;External Dimension: 230*420*217.6mm

V5-4018

Suitable motor:18.5KW; rated output current: 37A;External Dimension: 230*420*217.6mm

V5-4022

Suitable motor:22KW; rated output current: 45A; External Dimension: 290*450*217mm

V5-4030

Suitable motor:30KW; rated output current: 60A; External Dimension: 290*450*217mm

V5-4037

Suitable motor:37KW; rated output current: 75A; External Dimension: 375*581*261mm
