Double End Tenoner
Model | Working size | OD for tools | ID for tools | ||||||||
Length | Thickness | Scoring saw | Cut-off saw | Milling cutters | Scoring saw | Cut-off saw | Milling cutters | ||||
FMD8620 | 250~2000 | 6~80 | Ø 160 | Ø 300 | Ø 125~ Ø 180 | Ø25.4 | Ø 35 | Ø40 | |||
FMD8625 | 250~2500 | ||||||||||
FMD8630 | 250~3000 | ||||||||||
| |||||||||||
Motor power | Feeding speed | Weight( Tons approx) | Size (L×W×H) mm | ||||||||
Scoring saw | Cut-off saw | Milling cutter | |||||||||
2.2KW | 4KW | 5.5KW | 5~25m/min | 5.0T | 3880×3300×1800 | ||||||
5.3T | 4380×3300×1800 | ||||||||||
5.6T | 4880×3300×1800 | ||||||||||
Options:
1. Lengthen convey belt extend machine cover 1100mm.
2. Adopted Digital controlled system, servo motor for feeding and widen.
3. Jumping device for scoring saw
4. Electrical centralized lubricant system.
5. Inverter motor for cut-off saw, rotation speed can up to 4500r/min.
6. CE norm
Advantage
1. Electrical movement for the pressure belt with the pneumatic locked and controlled by digital positioner.
2. Machine base is processed by big CNC machine, over 1300mm width. Two high precision linear orbits are assembled and with steel dusty proof to protect.
3. All the tools with protection cover. Under the saws, there has over 400mm width 90° dust collector, easy to clean.
4. With the special location locked system and the little fence against the work pieces just with the surface, so it will not leave pressed mark in the work pieces.
5. High speed spindle (8000r/min)
6. High precision lightweight convey belt is assembled with bearings. High feeding speed and less noise, it is suitable for high speed processing
FIRMY MACHINERY CO.,LTD is a Sino-foreign joint venture with 20 years of experience in precision machining.Since it was established,FIRMY MACHINERY CO.,LTD has engaged in developing , manufacturing and marketing injection moulding machines, glass machines and made a great achievement in his development.
In 2007, FIRMY MACHINERY strongly stepped in the industry of China's Top -grade woodworking machinery. With its abundant technical strength, FIRMY has developed and manufactured four -side moulders,double-end tenoners,flooring production line, wood door production line and other woodworking machines and achieved its goal to keep abreast of the technology development of Germany and Italy in developing new products, owing to its introduction of high-tech and self-innovation. In the wake of continuously improving product quality, expanding market market share and glowing comprehensive strength, in recent years, FIRMY's products are in abundant supply in domestic market and developing actively in the international market, while many distributors from Europe, America and South Asia apply for become agents of FIRMY's products, which enjoy high reputation in both domestic and international markets, owing to their economy, dynamic,reliability and durability.
