Types Ammeters Manufacturers Three Phase Digital Current Meter

Technical Index

Accuracy Measurement

Current

 class 0.5

Input Measurement

Wiring

Rated value

AC 1A,AC 5A

Overload

Sustained:1.2times;Instantaneous:10times/5s

Power consumption

<0.4VA(per phase)

Impedance

<20 mΩ

Frequency

45~65Hz

Power supply

Working range

AC/DC 80V~270V,AC 220V,AC 380V,AC 100V

Power consumption

<4VA

Functional Module

Communication interface

Switching value input

4 loops switching value input, dry joint

Switching value output

4 loops relay output, capability: AC 250V/5A,DC 30V/5A

Transmission output

3 loop analog output: 0/4~20 mA or 0~5/10 V

Environment

Operational environment

-10℃~+55℃

Storage environment

-25℃~+70℃

Relative humidity

≤93 %,in the place without corrosive gas

Height above sea level

≤2500m

Safety

Insulation resistance

> 100MΩ

AC withstand voltage

AC 2KV

Electro Magnetic Compatibility

Electro-Static discharge

class 4

Electrical Fast Transient pulse train

Electrical surge

Outline Dimension

External Dimension( mm )

120×120;80×80;96×48;96×96;72×72;48×48;120x60;160x80

Cutout Dimension( mm )

111×111;76×76;92×45;92×92;68×68;45×45;114x56;152x76

Specification Matching

Model

Function

Measurement

Display

Cutout

Dimension (mm)

External

Dimension(mm)

3-phase AC

voltage

Switch

input

Switch

output

Transmission

output

Communication

interface

LED

 LCD

ME-3AV11

√

1

1

√

-

152X76

160x80

ME-3AV23

3

√

-

111X111

120×120

ME-3AV2Y

√

3

√

ME-3AV33

√

-

92X92

96×96

ME-3AV3Y

√

√

ME-3AV41

√

-

114X56

ME-3AV51

√

1

√

-

96×48

ME-3AV63

√

-

68X68

72×72

√

1

ME-3AV73

√

-

76X76

ME-3AV7Y

√

1

ME-3AV83

√

-

45X45

   Note: The number of optional extended functions would be the maximum number we can extend in
normal conditions.If you have any special request, please contact with our technical department.
