Product Details
Place of Origin: | Zhejiang, China | Brand Name: | CNRX | Model Number: | BV2.5 BV4 BV6 BV8 BV10 BV16 |
Insulation Material: | PVC | Type: | Low Voltage | Application: | Construction |
Conductor Material: | Copper | Jacket: | Other, non |
Product Description
Specifications
1.electric power cable
2.Professional supplier
3.Reliable quality,best price
4.Strong capacity,fast delivery
5.Copper wire
BV type 2.5 to 185mm2 Cu/Al pvc insulated wire with rated voltage up to 450/750V
General Description of PVC Insulated Building Wire Series:
1. Application
The PVC insulated wires belong to the series of laying wires, which are mainly suitable laid at fixed places.
a. They are usually used as connectors of driving, lighting, electric equipment, instrument and telecommunication equipment with rated voltage up to 450/750V (U0/U).
b. Part of the PVC insulated wires can be used at the equipment with alternating current rated voltage up to 300/300V.
2. Type, Name and application
Standard &Type | Name | Laying place and requirement | Long term working Temperature 0C |
60227IEC01 05 BV BLV | Copper conductor PVC insulated wires Aluminum conductor PVC insulated wires | Fixed laid indoors Conduit etc. | 70 |
60227IEC07 (BV-90) | Heat resistant copper conductor PVC insulated wire at 90 0C | Mainly be laid at the places of high temperature environment and can be laid indoors, conduits. | 90 |
BVR | Copper conductor PVC insulated flexible wire | Be for laying permanent place where flexible required. | 70 |
60227IEC10 (BVV) BVV | Copper conductor PVC insulated PVC sheathed round wires | Fixed laid, fit for the places with high mechanical protection and moisture place, can be laid in the air or underground. | 70 |
BLVV | Aluminum conductor PVC insulated PVC sheathed round wires | ||
BVVB | Copper conductor PVC insulated PVC sheathed flat wires | ||
BLVVB | Aluminum conductor PVC insulated PVC sheathed flat wires | ||
60227IEC02(RV) 60227IEC06(RV) | Copper conductor PVC insulated flexible connector wire | Mainly used at middle and light style moving electronics, home appliances, power and lighting and the places where flexible required | 70 |
60227IEC42(RVB) | Copper conductor PVC insulated flat flexible connector wire | ||
RVS
| Copper conductor PVC insulated flexible twisting connector wire | ||
60227IEC52(RVV) 60227IEC53 | Copper conductor PVC insulated PVC sheathed round flexible connector wire | ||
60227IEC08 (RV-90)
| Cu conductor heat resistant PVC insulated flexible connector wire at 90 0C | Mainly used at the places where heat resistance is required | 90 |
1 Our loyal purport: Based on sincerity! Serve the first!, your trustworthy parter
2 Devoted in the power transmission and distribution since 1995, having lots of experienced
engineer and workers
3 We are able to contract foreign project obtained the qualification certificate
1. Which payment terms do you accept?
a.The payment term varies with different price level and total rate of each contract.
The following are most common terms:
b. 30% T/T down payment, the balance before you picking up the goods.
c. 100% L/C at sight.
d. 30% T/T down payment, the balance against 100% L/C at sight.
2. What is your MOQ?
You are advised to please confirm it with us directly as it’s based on different cable type.
Usually it’s 500 meters for Medium Voltage Cables.
3. What about the lead time for our cable product ?
The lead time according to the your order's quantity.Usually our lead time is 10 - 30 wrking days.
4. What about our product's package ?
our product's package usually is wooden drum or steel-wooden drum.The cable wire is usually coiled.
For more information on detailed cable characteristics please call 86 577 57185601
Or email us your request for design cable and wire.
