Specifications
Electric Wire
1 Conductor: Flexible (Class 5) Copper
2 Standard:BS 6004, IEC 60227
3 Rated Voltage:300/500V,450/750V
Flexible CU/PVC Electric Wire
1 Description
Construction: Flexible annealed copper wire as conductor (Class 5), PVC insulated single core wire.
Code Name: H05V-K ( 0.5mm2 ~ 1.0mm2 ); H07V-K ( 1.5mm2 ~ 240mm2 )
Voltage: 300/500V for H05V-K; 450/750V for H07V-K.
2 Application
The non-sheathed single core flexible wire is used for wiring of switch control, relay and instrument panels of power switch-gear, and such purpose as internal connections in rectifier equipment and in motor starters and controllers.
3 Manufacturing Standards
GB/T 5023-2008, BS 6004, IEC 602271
Code Name |
Nominal conductor area |
Number of wires |
Nominal diameter of wire |
Nominal thickness of insulation |
Approx. Overall diameter |
Max. Conductor DC resistance at 20oC |
mm2 |
No. |
mm |
mm |
mm |
Ω/km |
|
H05V-K |
0.5 |
16 |
0.20 |
0.6 |
2.1 |
39.0 |
0.75 |
24 |
0.20 |
0.6 |
2.3 |
26.0 |
|
1.0 |
32 |
0.20 |
0.6 |
2.5 |
19.5 |
|
H07V-K |
1.5 |
30 |
0.25 |
0.7 |
3.0 |
13.3 |
2.5 |
50 |
0.25 |
0.8 |
3.6 |
7.98 |
|
4 |
81 |
0.25 |
0.8 |
4.2 |
4.95 |
|
6 |
121 |
0.25 |
0.8 |
4.8 |
3.30 |
|
10 |
77 |
0.40 |
1.0 |
6.5 |
1.91 |
|
16 |
126 |
0.40 |
1.0 |
7.8 |
1.21 |
|
25 |
196 |
0.40 |
1.2 |
9.7 |
0.780 |
|
35 |
280 |
0.40 |
1.2 |
11.5 |
0.554 |
|
50 |
380 |
0.40 |
1.4 |
13.1 |
0.386 |
|
70 |
350 |
0.50 |
1.4 |
15.5 |
0.272 |
|
95 |
475 |
0.50 |
1.6 |
17.6 |
0.206 |
|
120 |
600 |
0.50 |
1.6 |
19.7 |
0.161 |
|
150 |
750 |
0.50 |
1.8 |
22.0 |
0.129 |
|
185 |
925 |
0.50 |
2.0 |
24.1 |
0.106 |
1 Our loyal purport: Based on sincerity! Serve the first!, your trustworthy parter
2 Devoted in the power transmission and distribution since 1995, having lots of experienced
engineer and workers
3 We are able to contract foreign project obtained the qualification certificate
For more information on detailed cable characteristics please call 86 577 57185601
Or email us your request for design cable and wire.
