Product Details
Place of Origin: | Zhejiang, China | Brand Name: | CNRX | Model Number: | RX200M-72 |
Specification: | Normal | Application: | Home | Output Voltage (V): | 36V |
Load Power (W): | 200W | Solar Power (W): | 200W | Work Time (h): | 24hr |
Product Description
Overview
- High cell efficiency PV solar panel with quality silicon material for long term output stability and reliability.
- Rigorous quality control to meet the highest international standards.
- High transmittance, low iron tempered glass with enhanced stiffness and impact resistance.
- Unique frame design with high mechanical strength for easy installation.
- Advanced encapsulation material with multilayer sheet lamination to provide long-life and enhanced cell performance.
- Outstanding electrical performance under high temperature and low irradiance conditions.
- 72 Back-Contact monocrystalline Si solar cells (approx. 18.32%).
Applications
- Commercial/ industrial building PV solar roof-top off-grid systems.
- Residential PV solar roof-top off-grid systems.
- Any commercial / industrial ground mount off-grid systems.
- Other off-grid industrial and commercial solar PV applications.
Warranty
- 10 year limited product warranty on materials and workmanship.
- 25 year limited power warranty on power output.
- ≥90% power output assurance for 10 years and ≥80% power output assurance for 25 years.
- Refer to warranty document for detailed warranty information.
Certifications
- TUV(IEC61215 IEC61730)
- CE
- ISO
Electrical Characteristics
All specified Parameters are at STC 25℃Ambient, 1000W/ m irradiance and AM 1.5
Type | RX295M-72 | RX300M-72 | RX305M-72 | RX310M-72 | RX315M-72 |
Max-Power Pm(W) | 295 | 300 | 305 | 310 | 315 |
Module-Power Range(W) | 300>Pm≥295 | 305>Pm≥300 | 310>Pm≥305 | 315>Pm≥310 | Pm≥315 |
Power Tolerance(W) | +0~+5 | +0~+5 | +0~+5 | +0~+5 | +0~+5 |
Max-Power Voltage(V) | 34.7 | 35 | 35.3 | 35.6 | 35.9 |
Max-Power Current lm(A) | 8.51 | 8.58 | 8.65 | 8.71 | 8.78 |
Short-Ciruit Current lsc(A) | 9.25 | 9.3 | 9.35 | 9.4 | 9.45 |
Open-Circuit Voltage Voc(V) | 41 | 41.3 | 41.7 | 42 | 42.3 |
Max-System Voltage(VDC) | 1000V(IEC) | ||||
Cell Efficiency(%) | 17.1 | 17.4 | 17.7 | 18 | 18.3 |
Module Efficiency(%) | 15.2 | 15.5 | 15.7 | 16 | 16.2 |
Max.Series Fuse(A) | 15 | ||||
Pm Temperature Coefficients(W/℃) | -1.1041 | ||||
Lsc Temperature Coefficients(A/℃) | 0.00418 | ||||
Voc Lsc Temperature Coefficients(V/℃) | -0.1261 | ||||
NPCT Nominal Operating Cell Temperature | 47±2℃ |
Mechanical Characteristics
Cable type,Diameter and Length | 4mm,TUV certified,900mm |
Type of Connector | Compatible Type IV |
Number,type and arrangement of cells | 72 pcs,Mono-Crystalline Silicon(6×12) |
Cell Size(mm) | 156×156(D200) |
Dimension(mm) | 1950×990×45 |
Weight(kg) | 26 |
No.of Draining Holes in Frame | 10 |
Glass,Type and Thickness | High Transmission,Low lron,Tempered Glass 3.2mm |
Packaging Configuration
Packing Configuration | 22 pcs/box |
Quantity/Pallet | 44 pcs/pallet |
Loading Capacity | 528 pcs/40ft |
Absolute Ratings
Dielectric Insulation Voltage | 3000V |
Operating Temperature(℃) | -40~+85 |
Storage Temperature(℃) | -40~+85 |
