Solar Productions

Name: Solar Productions
Brand: CNRX
SKU: 129083789
Availability: InStock

US$ 120 - 125 MOQ: 25 Units

Key Specifications

Place of Origin:

Zhejiang, China

Brand Name:

CNRX

Model Number:

RX250P-60

Ruixin Group Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Shanghai/Ningbo

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Zhejiang, China

Brand Name CNRX

Model Number RX250P-60

Specification Normal

Application Home

Output Voltage (V) 30V

Load Power (W) 250W

Solar Power (W) 250W

Work Time (h) 24hr

Overview

High cell efficiency PV solar panel with quality silicon material for long term output stability and reliability.
Rigorous quality control to meet the highest international standards.
High transmittance, low iron tempered glass with enhanced stiffness and impact resistance.
Unique frame design with high mechanical strength for easy installation.
Advanced encapsulation material with multilayer sheet lamination to provide long-life and enhanced cell performance.
Outstanding electrical performance under high temperature and low irradiance conditions.
60 Back-Contact polycrystalline Si solar cells (approx. 17.5%).

Applications

Warranty

10 year limited product warranty on materials and workmanship.
25 year limited power warranty on power output.
≥90% power output assurance for 10 years and ≥80% power output assurance for 25 years.
Refer to warranty document for detailed warranty information.

Certifications

Electrical Characteristics

All specified Parameters are at STC 25℃Ambient, 1000W/ m irradiance and AM 1.5

Type	RX250P-60	RX230P-60	RX235P-60	RX240P-60	RX245P-60
Max-Power Pm(W)	250	230	235	240	245
Module-Power Range(W)	255>Pm≥250	235>Pm≥230	240>Pm≥235	235>Pm≥240	Pm≥245
Power Tolerance(W)	+0~+5	+0~+5	+0~+5	+0~+5	+0~+5
Max-Power Voltage(V)	30.9	30.2	30.5	30.8	31.1
Max-Power Current lm(A)	8.1	7.62	7.71	7.8	7.89
Short-Ciruit Current lsc(A)	9.1	8.31	8.4	8.55	8.65
Open-Circuit Voltage Voc(V)	36.9	36.9	37	37.2	37.4
Max-System Voltage(VDC)	1000V(lEC)s
Cell Efficiency(%)	17.2	15.8	16.1	16.4	16.8
Module Efficiency(%)	15.3	14	14.3	14.6	14.9
Max.Series Fuse(A)	15
Pm Temperature Coefficients(W/℃)	-1.171
Lsc Temperature Coefficients(A/℃)	0.0047
Voc Lsc Temperature Coefficients(V/℃)	-0.1261
NPCT Nominal Operating Cell Temperature	47±2℃

Mechanical Characteristics

Cable type,Diameter and Length	4mm,TUV certified,900mm
Type of Connector	Compatible Type IV
Number,type and arrangement of cells	60 pcs,poly-Crystalline Silicon(6×10)
Cell Size(mm)	156×156
Dimension(mm)	1650×990×40
Weight(kg)	22.5
No.of Draining Holes in Frame	10
Glass,Type and Thickness	High Transmission,Low lron,Tempered Glass 3.2mm
