Specifications
1.Name:Hydraulic tubing power tong2.Size:XQ140/12YA, XQ114/6YB, XQ89/3YC
3.Widely used in onshore or offshore oilfieds
Detailed description
Hydraulic Tubing Power Tong is used for quick make-up or break-out in well service operations. The tong is equipped with hydraulic backup tong and use inner curved cam to clamp.
Product performance:
features | |
1.clamp the tubing use corresponding dies, jaw set or die seat. | |
2.torque control valve may be equiped according to customer’s request. | |
3.choose and buy lengthening guide pole assembly, the backup tong can clamp the tubing body | |
4.torque control system may be equiped according to customer’s request. | |
Model |
XQ140/12YA |
Pipe size range of master tong |
φ73-140 27/8”-51/2” |
Pipe size range of backup tong |
φ89-156 37/2”-61/8 |
High gear rated torque |
2600 N.m 1918 ft-lbs |
Low gear rated torque |
12000N.m 8851 ft-lbs |
Hige gear rated speed |
72r/min |
Low gear rated speed |
14r/min |
Rated operation pressure |
12Mpa 1470psi |
Max. Flow |
120L/min 32gpm |
Dimension:L×W×H |
1024×582×539 40.3” ×22.9” ×21.2” |
Weight(including backup tong) |
480kg 1057 lbs |
