FXBW series suspension composite insulators
Specifications
suspension composite insulators
1.Application:High Voltage
2.CE ROHS CCC
SMICO FXBW series suspension composite insulators
product prorerty
• Good electrical specification, strong mechanical strength, tensile bending intension of the epoxy glass fiber rod of internal load bearing is double than normal rolled products, 8-10 times of high strength porcelain material, can effectively improve the reliable of safe operation.
• Fine anti-pollution, strong prevent flash accident, and the wet withstand voltage and pollution withstand voltage is 2-2.5 times than the same creep age distance porcelain insulator, and not to cleanup, can safe operate in the serious pollution areas.
• Small volume, lightweight (only for the same voltage grade of porcelain insulator 1/6-1/9), lightness structure, to easy for transportation and installation, the shed has favorable waterproof performance .which the whole structure assure the internal insulation is not wet, not need to test of prevent insulation and cleanup, to reduce the routine maintenance work capacity.
Details
Product Model |
Rated voltage (kV) |
Rated mechanical load(KN) | Structure height H.(mm) | Insulating distance Li. (mm) |
Min Creep age distanee(mm) |
Lightning impulse withstand voltage (peak)(kV) |
P.Fwet withslend voltage (virtual value)(kV) |
| FXBW4-12/70 | 12 |
70 |
370 | 200 | 480 | 75 | 42 |
| FXBW4-12/100 | 12 |
100 |
405 | 200 | 480 | 75 | 42 |
| FXBW4-24/70 | 24 | 70 | 550 | 370 | 850 | 185 | 75 |
| FXBW4-24/100 | 24 | 100 | 590 | 370 | 850 | 185 | 75 |
| FXBW4-35/70 | 35 | 70 | 650 | 450 | 1225 | 230 | 95 |
| FXBW4-35/100 | 35 | 100 | 690 | 450 | 1225 | 230 | 95 |
| FXBW4-66/70 | 66 | 70 | 900 | 710 | 1980 | 410 | 185 |
| FXBW4-66/100 | 66 | 100 | 940 | 710 | 1980 | 410 | 185 |
| FXBW4-110/70 | 110 | 70 | 1240 | 1000 | 3315 | 550 | 230 |
| FXBW4-110/100 | 110 | 100 | 1240 | 1000 | 3315 | 550 | 230 |
| FXBW4-220/100 | 220 | 100 | 2240 | 1900 | 6300 | 1000 | 395 |
| FXBW4-220/160 | 220 | 160 | 2240 | 1900 | 6300 | 1000 | 395 |
| FXBW4-330/100 | 330 | 100 | 2950 | 2600 | 9075 | 1425 | 570 |
| FXBW4-330/160 | 330 | 160 | 2950 | 2600 | 9075 | 1425 | 570 |
| FXBW4-500/160 | 500 | 160 | 4080 | 3730 | 12750 | 2250 | 740 |
product
1.Can off CO,Form B ,Form A and others
2.Supply OEM/ODM
3.Can be customerized
1.Q: How is your quality ?
A: The quality of our products are very good ,we accept customers to test them .
2.Q: How is your price ?
A: Cheaper price with good quality ,we can not say our price is the lowest in China .but we can say our price is cheaper than most factory in China
3.Q: Do you have quality certificate ?
A: Yes,we have ,we have ISO-9001 certificate and CE ,CB ,CCC certificate .
4.Q: How long is your warranty time for your product?
A: Warranty time:one and half year ,any problem caused by quality can be changed by new in your next order .
5.Q: Are those pictures real pictures of your factory ?
A: Of course 100% real pictures of our factory ,you can not find them on internet !
6.Q: Can you offer free sample to test quality ?
A: Yes ,we can .wish to cooperate with you in the future .
