Specifications
HPG1810 H I C BOX pipe plate steel sand blasting shot blasting machineblasing material: steel sand
1. Workpiece of HPG1810 H I C BOX pipe plate steel sand blasting shot blasting machine
Specifications of work-piece
Steel plate: Width<1800mm Thickness 6-30mm Length> 3000mm
Section steel: max section size (width×height) ≤1000×1800mm
Steel tube, angle steel, C-channel, I-beam and H Beam: length ≥3000mm
Steel structure: max section size (width×height) ≤800×1600mm
Length ≥3000mm (work piece that could be running on the conveyor)
Shot-blasting quality grade:ISO850-1: 1988 A-B Sa2-Sa2.5 grade
Work-piece processing speed: V=0.6-3.0m/min
Total capacity: about 130.4Kw.
Note: the machine can be desugned accroding to different size of steel products.
2.Purpose of HPG1810 H I C BOX pipe plate steel sand blasting shot blasting machine
The work-piece is transported by conveying roller system, go passing through the front chamber, entering into the shot-blasting chamber. The blasting wheels installed on the blasting chamber will make use of the impeller rotating in high speed to shot out the steel grit and hitting on the surface of the work-piece to remove the oxidation skin, rust, feculence to reach the cleaning and elimination purpose. Then the work-piece will go through the back chamber then transported out by the conveying roller. Then the worker can do manual bottom painting on work-piece. Therefore to each the purpose of making steel material de-rusting and preventing from rusting.
3.Machine seat and support column process of HPG1810 H I C BOX pipe plate steel sand blasting shot blasting machine
Steel box column processed on CNC machining center, to make sure good fitting and high strength
4.Strict and serious quality testing for HPG1810 H I C BOX pipe plate steel sand blasting shot blasting machine
There are two moving quality inspectors at each process, and the manager for each shift and monitor the production closely. Inspect and correct the parts after machining before assembling.
5.Factory and Workshop show for HPG1810 H I C BOX pipe plate steel sand blasting shot blasting machine
6. Package and shipment for HPG1810 H I C BOX pipe plate steel sand blasting shot blasting machine
7. Warranty and Service after sales for HPG1810 H I C BOX pipe plate steel sand blasting shot blasting machine
Warranty time: 12months since machinery installation finished.
Service after sales:
Professional Installation and training at customer spot factory,during time decides by different machine.
Lower price of consumable parts than markets .
Trouble response: 24hours online reply. If broken parts is not comsumable parts or breaks by wrong operation, we can send the broken parts free once confirmed.
Engineer service available overseas.
