Help Center350W 12v 24v 48v UPS Backup Battery for Door Access Control Systerms
Related Products
-
90W 24v+27.6V DC-UPS Dual Output Power Supply From China FactoryUS$ 6 - 13MOQ: 1 Piece -
120W DC-UPS Chargeable Switching Power Supply From Chinese FactoryUS$ 10 - 18MOQ: 1 Piece
-
40W DC-UPS Chargeable Switching Power Supply From Chinese FactoryUS$ 5 - 9MOQ: 1 Piece
-
Dual Output DC12V DC13.8V Chargeable UPS Power SupplyUS$ 6 - 13MOQ: 1 Piece
-
40W DC-UPS Switching Power Supply From Chinese FactoryUS$ 5 - 9MOQ: 1 Piece
40W~130W PCB switching power supply
High quality,competitive price
High efficiency, low temperature
Product: Light/ Thin/ Short/ Small
Built-in EMI filter, low ripple noise
100% full load burn-in test
Protections: Short circuit/ Over load
350W DC-UPS |
case:K810 215×115×50mm |
|||||
Features: | ||||||
Product:Small Size, High efficiency | ||||||
Universal AC input/ Full range | ||||||
Protections:Short circuit/Over load | ||||||
Charging/discharging switch automatically | ||||||
Battery under voltage protection | ||||||
Fully charge discharge instructions | ||||||
Input voltage range -----------176~264V AC | ||||||
Over load protection ------105%~150%(rated load),Auto-recovery | ||||||
Charge mode --------rated voltage,(current)charge | ||||||
Withstand voltage---------- Input-Output: AC1.5KVACV,1min; | ||||||
Working temperature ------ -10~+50℃@100%, 60℃@60%load | ||||||
Safety standards -----------MeetGB4943 | ||||||
Weight---------------1.1kg | ||||||
Code |
Item No. |
Output |
Tol. |
R&N |
Effi. |
|
1020 |
KDC350-12 |
+12V,25A |
±10% |
100mV |
80% |
|
|
|
+13.8V,4A |
±2% |
|
|
|
1021 |
KDC350-24 |
+24V,12A |
±10% |
200mV |
85% |
|
|
|
+27.6V,2A |
±2% |
|
|
|
1022 |
KDC350-48 |
+48V,6A |
±10% |
200mV |
85% |
|
|
|
+54V,2A |
±2% |
|
||
Product Application
• Power tools series: Electric Saw, Drilling Machine,Sand blast Machine, Puching Machine,
Weeding Machine,Air Compressor etc.
•Office series: Computer,Printer,LCD Monitor,Scanning Machine, Audio-visual products,Security
monitor,computer chassis etc.
• Household Appliance series: Dust Collector,Fan Lamp or LED ,Sewing Machine, air cleaner, electronic refrigerator, etc.
• Kitchen Appliance series: Microwave Oven, Fridge, Coffee marker etc.
• Industrial Equipment series: shipping,vehicle,metalhalide lamp,solar system,wind power
generation ,Industrial automation control,Industrial control equipment,
• Electrical filed series: TV,VCRS,Radio,military equipment, research equipment,communication equipment,medical equipment,digital product etc.
