Chinese 1.5ton Log Loader TY18 With Wood Grapple Bucket

Chinese 1.5ton Log Loader TY18 With Wood Grapple Bucket thumbnail-1
Chinese 1.5ton Log Loader TY18 With Wood Grapple Bucket thumbnail-2
Chinese 1.5ton Log Loader TY18 With Wood Grapple Bucket photo-1
Chinese 1.5ton Log Loader TY18 With Wood Grapple Bucket photo-2
Negotiable MOQ: 1 Unit (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Condition:
New
Brand Name:
TAIAN
Model Number:
TY18
Contact Supplier Request Quote Chat Now
Taian Dongyue Carrying Machinery Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Qingdao
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Condition New
Brand Name TAIAN
Model Number TY18
Place of Origin Shandong, China
Type Front Loader
Moving Type Wheel Loader
Dimension(Long * Breadth * High) 4650x1870x2720mm
Rated Load 1500kg
Certification CE and ROPS
Warranty one year or 1000 working hours whichever comes first
After-sales Service Provided Overseas third-party support available

chinese 1.5ton log loader TY18 with wood grapple bucket :



1.0 Engine Details

(1) Model: YUNNEN4102GB

(2) Engine type:In-line arrangement, water-cooled, four-cycle diesel Engine

(3) Rated Power:60KW (81H.P.)

(4) Rated Speed:2400 r/p.min (rpm)

(5) Fuel Consumption ratio in standard working condition: 180g/kw.h



2.0 Transmission System

Hydraulic converter + drive shaft + axles



3.0 Bucket

(1) Bucket Capacity: 0.8 m3

(2) Bucket width: 1700mm

(3) Bucket type:Heavy-duty bolt on teeth

(5) Rated Load: 1500kg including attachment



4.0 Overall Dimensions

(1) Overall Length: 4650mm

(2) Overall Height:2720mm

(3) Overall Width: 1870mm

(4) Max. lifting Height:3450mm



5.0 Operating Specifications

(1) Steering System: Articulated Frame with hydraulic power steering

(2) Min Turning Radius: 4950mm

(3) Driving System: Hydraulic converter, four wheel drive

(4) Quick coupling system

(5) Joystick

(6) Self levering



6.0 Brake System

(1) Service Brake:Four Wheel Chuck brake

(2) Parking Brake:Hand operated



7.0 Tyre

(1) Model:17.5-16, 12ply (2)Width: 307mm(3) Diameter: 831mm



8.0 Wheelbase: 2400mm


9.0 Track: 1345mm



10. system pressure:20Mpa; Hydraulic output:96L/min

 You are warmly welcomed to visit our factory.
