Home > Consumer Electronics > Water Heater & Components > Solar Water Heater > Hot Sale Selective Coating for Heat Pipe Vacuum Tube Solar Collector
Hot Sale Selective Coating for Heat Pipe Vacuum Tube Solar Collector
US$ 600 - 900
MOQ: 100 Sets
Key Specifications
Get Latest Price
Type:
Evacuated Tube
Pressure:
Pressurized
Circulation Type:
Indirect / Closed Loop (Active)
Payment & Shipping
Payment Methods:
Port of Shipment:
Kaohsiung Taiwan
Delivery Detail:
Delivery time depends on order quantity.
Related Products
Type
Evacuated Tube
Pressure
Pressurized
Circulation Type
Indirect / Closed Loop (Active)
Heating System
Batch / ICS (Passive)
Connection Type
Split
Installation
Wall Mounted
Housing Material
Other
Certification
Other, Solar Keymark & SRCC ( Applying)
Place of Origin
Taiwan, China
Brand Name
YUHO
Model Number
SQ58/30
Specifications
Heat pipe vacuum tube solar water heaterAluminum manifold
Aluminum frame
Pressure resistance: 7kg
Made in Taiwan
vacuum solar collector china Heat pipe vacuum tube solar water heater
| Vacuum tube | 30 / 20 tubes |
| Thermal collector | |
| Absorber | heat pipe vacuum tube |
| Absorption | ≥0.86% |
| Emission | ≤0.08% |
| Coating | AL/AL-ALN; CU/SS-ALN |
| Manifold | |
| Material | Copper |
| Casing | Aluminum |
| Connection | 3/4" |
| Pressure Resistance | 7 kg |
| Evacuated tube | |
| Diameter | Ø58 mm |
| Length | 1700mm |
| Material | High Boron Silicon Glass 3.3 |
| Thickness | 1.6mm |
| Dimension | 2010*2000*135mm |
| Antifreeze: | Antifreeze liquid refers to the local relevant standard. Leng
|
The heat pipe of vacuum tube thermal collector can absorb the radiation and then to store
the energy in the manifold. The circulating pump is pumping the water or liquid from the manifold to the water storage tank. The whole system pushes the hot water down to the storage tank as well as pushing the cold water up into the manifold and then to absorb the solar radiation in the meanwhile. But the work station can get the different temperature of water between the storage tank and manifold, and then to control the circulation pump ON or OFF. Therefore, it is easy to retrofit the whole system as it can Increase or decrease the numbers of thermal collectors when it is required to do so.
Application: Residential, condo, resort, apartment, hotel, motel, tour van and industries.
ISO 9001 Certification
Send Inquiry to This Supplier
* Email
Want the best price?
Post an RFQ now!
Business Type
Manufacturer
Year Established
2000
Factory Size
1,000-3,000 square meters
Total Employees
11 - 50 People
