Home > Products > Ground screw machine > pile drilling machine price
pile drilling machine price
- 30 Unit / Units per Month
- Qingdao China
- T/T D/P D/A PayPal
Product Details
Condition: | New | Place of Origin: | Shandong, China | Brand Name: | TAIAN |
Model Number: | PD4000 | Weight: | 4560kgs | Dimension(L*W*H): | 4370mm*1850mm*3450mm |
After-sales Service Provided: | Engineers available to service machinery overseas |
Product Description
pile drilling machine price
drilling machine
High-end practical cabin, elegant appearance, security and comfortable inside;
Equipped with air conditioning, adjustable elastic damping seat;
Full electronic instrument display, the running state of machine is visible inside;
Multifunctional electronic control joystick, with comfortable operation and reducing the work intensity;
Drill mast mounting with electronic inclinometer, easy to adjust and monitor in the cab.
Model | PD4000 |
Max. Length | 4370mm |
Max. width (mm) | 1850mm |
Max. height (mm) | 3450mm |
Turning angle | 320 |
Speed | 17km/h |
Weight | 4660kg |
Standard Tyre | 20.5-16 |
Tyre pressure bar | 2.8 bar |
Oil tank capacity | 40 L |
System pressure | 190bar |
Rod diameter | 76-90 mm |
Max. Drilling depth | 4000mm |
Oil model | L-HL46 |
Engine | Yunnei 4102 |
Cooling system | Water cooled |
Rated power | 60kw |
Rotating speed | 2400 r/min |
Fuel tank capacity | 40 L |
Battery | 105AhX2 |
Voltage | 24 V |
1.For the new machine, within determined limits, the manufacture guarantees for a period of 12 months after bought or 1000 working hours(whichever comes first).
2.The warranty includes repairation or replace the parts for free which were proved to be defective in origin by the technical department of the manufacture.
3.The repairation or replacement for the parts should not exceed the warranty period.
4.The warranty is valid on the condition of all the terms listed in the contract was observed.
If you are interested in this machine and need a quotation, Please contact with: Steven.
