SGW Electric Chain Hoist Stage Lifting Electric Chain Hoist

stage lifting electric chain hoist

SGW Electric chain hoist

Capacity:0.5t,1t,2t,3t,5t,7,5t,10t,15t,25t,30t,35t.

Motor: Work class F insulation. Duty rating:45%.Aluminum alloy motor with light weight and good heat dissipation to allow up 30minof continuous duty work at least.

Gear: All the gearing process by CNC Digital lathe with heat treating

Shelly:Made of light aluminum alloy shell.Light&hard. The cooling fin is especially designed to ensure quick heat dissipationwith the rate up to 45% and continuous service. The integral enclosed structure is applicable to places like chemical plate andelectroplate factroy

Side magnetic braking device:The magnetic orce generator is the lastest design which is featured for generating magnetic force. It allowsinstant brake cut off electric power asap.Keep the braking safety while loading is guaranteed

Limit switch :The limit switch automatically stop the hoist overlifting or overlowering

Chain: FEC JAPAN made G-80 super alloy steel chain.Heat treated to used in harsh environments .

Hook: Hot fored with perfect strength and tough with saftey latch on the top&bottom hook. Bottom hook swivels through 360°

Support frame:The loading support frame consists of two steel plates which is extremely sturdy

Transformer:24/36V transformer device forbid unexpected accidents such as electric leakage.

Electromagnetic contactor:It can use safely under high frequency

Phase protect device: It wonn't work when error wiring connecting by the end user to keep safe

Control button: IP 54 protection on electric hoist for dust and water proof protection.36V control
