Electric Chain Hoist

Chongqing Kinglong Machinery Co., Ltd.

Negotiable MOQ: 1 set (Price negotiable depending on order volume and customization)

Key Specifications

Place of Origin:

Chongqing, China

Model Number:

1Ton - 20Ton

Usage:

Drywall Panel Hoist

Payment & Shipping

Payment Methods:

Port of Shipment:

China

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Chongqing, China

Model Number 1Ton - 20Ton

Usage Drywall Panel Hoist

Power Source Electric

Sling Type Chain

Maximum Lifting Weight 20Ton

Maximum Lifting Height 3m

Specifications

the Double Swallow "brand DHT" Electric Chain Hoist has kept the light and handy and convenient characteristic

Model		DHT1	DHT1.5	DHT2	DHT3	DHT5-1	DHT5-2	DHT7.5-1	DHT7.5-2	DHT10-1	DHT10-2	DHT20-1	DHT20-2
Capacity	Ton	1	1.5	2	3	5	5	7.5	7.5	10	10	20	20
Lift	m	2.5	2.5	2.5	3	3	3	3	3	3	3	3	3
Test Load	Ton	1.25	1.87	2.5	3.75	6.25	6.25	9.375	9.375	12.5	12.5	25	25
Min.DistaMin. Between Hooks	mm	300	360	380	470	600	600	650	650	730	730	1000	1000
No. of load chain		1	1	2	2	2	2	3	3	4	4	5	5
Diameter of load chain	mm	6	8	6	8	10	10	10	10	10	10	10	10
Voltage	380V 50HZ
Power	kw	0.3	0.3	0.3	0.3	0.5	0.75	0.5	0.75	0.5	0.75	0.5	0.75
Lifting speed m./min	0.9	0.9	0.45	0.45	0.17	0.35	0.35	0.113	0.233	0.085	0.175	0.085	0.175
Net weight	kg	26	32	30	37	54	54	71	71	88	88	195	195
Get Weight	kg	28	34	32	42	65	65	85	85	102	102	235	235
Packing measurement(LXWXH)	cm	34x34x34	34x34x34	34x34x34	34x34x34	43x36x43	43x36x43	62x50x43	62x50x43	62x50x43	62x50x43	72x72x85	72x72x85
Extra weight per meter of extra lift	kg	0.8	1.4	1.6	2.8	4.4	4.4	6.6	6.6	8.8	8.8	17.7	17.7
