Home > Industrial Equipment & Components > Valve > Ball Valve > 3V Series Pneumatic Directional 2 Position 3 Port Single Control Solenoid Valve
3V Series Pneumatic Directional 2 Position 3 Port Single Control Solenoid Valve
US$ 10 - 200
MOQ: 10 Pieces
Key Specifications
Get Latest Price
Standard or Nonstandard:
Standard
Structure:
Pilot
Pressure:
Medium Pressure
Payment & Shipping
Payment Methods:
Port of Shipment:
ningbo/shanghai
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
2W Series Small Oriffice Solenoid ValveUS$ 5 - 15MOQ: 10 Pieces -
2W (UW) Series 2 Position 2 Port Direct Acting Solenoid ValveUS$ 5 - 100MOQ: 10 Pieces
-
2L Series High-temperature Solenoid ValveUS$ 20 - 200MOQ: 10 Pieces
-
2s Series Stainless Steel Solenoid ValveUS$ 10 - 100MOQ: 10 Pieces
-
2P Series Plastic Solenoid ValveUS$ 10 - 100MOQ: 10 Pieces
Standard or Nonstandard
Standard
Structure
Pilot
Pressure
Medium Pressure
Power
Solenoid
Material
Brass
Temperature of Media
Medium Temperature
Media
Water
Port Size
M5 1/8"1/4" 3/8" 1/2"
Place of Origin
Zhejiang, China
Model Number
3V
Brand Name
VPC or OEM brand
Specifications
Solenoid Valve1.Acting Type:direct acting
2.Coil Type:DIN type/Flyling lead
3.Protective Class:IP65(DIN40050)
4.100% test
3V series solenoid valve have single acting and double acting types. Single acting solenoid valves are mainly used in controling the single acting type cylinder, size from M5 to 1/2’’. According to the difference of the flow, valve body have many types are available. Din connector and flying leads types, different superficial treatment, G, NPT PT etc are available.
Specificaitons of 3v Series Solenoid Valve (2 Position 3 port single control)
| Model | 3V110-M5 | 3V110-06 | 3V210-06 | 3V210-08 |
3V310-08 | 3V310-10 | 3V410-15 |
| Working Medium | Clean Air (40 Micrometer Filteration) | ||||||
| Ways | 2 Position 3 Port | ||||||
| Acting Type | Direct Acting | ||||||
| Joint Size | Import=M5 Export=M5 |
Import=1/8 Export=1/8 |
Import=1/4 Export=1/4 |
Import=1/4 Export=1/4 |
Import=3/8 Export=3/8 |
Import=1/2 Export=1/2 |
|
| Sectional Area | 5.5mm2(CV=0.31) | 12mm2(CV=0.67) | 14mm2(CV=0.78) | 16mm2(CV=0.89) | 25mm2(CV=1.39) | 30mm2(CV=1.67) | 50mm2(CV=2.79) |
| Working Pressure | 0.15~0.9Mpa | ||||||
| Guarantee Pressure | 1.2Mpa | ||||||
| Working Temperature | -5~60°C | ||||||
| Voltage Range | -15%~10% | ||||||
| Heat Resistant Grade | B | ||||||
| Protective Class | IP65(DIN40050) | ||||||
| Coil Type | DIN Type,Flying Leads | ||||||
| Max Acting Frequency | 5 Times/s | 5 Times/s | 4 Times/s | ||||
