Help CenterVFS5000F4 Vertical Four Side Seal Bagging Filling Machine
Related Products
-
VFS5000E M-style Bagging Filling MachineUS$ 10,000 - 15,000MOQ: 1 Set -
VFS5000B Automatical Vegetables/rice Vertical Packing MachineUS$ 17,800 - 19,800MOQ: 1 Set
-
VFS7300YA5 Box Type Bag Vertical Packing MachineUS$ 18,500 - 21,500MOQ: 1 Set
-
VFS7300FS Washing Powder Automatic Packing MachineUS$ 14,800 - 16,500MOQ: 1 Set
-
VFS5000D Automatic Packaing MachineUS$ 14,500 - 16,500MOQ: 1 Set
Specifications
1) Automatically bagging, filling and packaging2) Four side sealing and high precision
3) Competitive price
The machine integrates into one the functions such as automatic weighing, filling, sealing, printing, punching, tearing notching and countering etc. into one. The shape of the packaging bag is bice and smooth; the range of bag making size is wide, the bag can be made into four-side d seal bags of several packaging materials. Has the advantage of high accurancy, stable performance and convenient operation and is suitable for automatic packaging of various kinds of granular materials.
This machine is high-precision four-side-seal bag packing machine and the dimension of bag making is adjustable.
Bag Type: |
Four Side Seal bag |
Speed: |
40-80BPM |
Bag Size: |
80 to 340mm(L); 70 to 240mm(W) |
Reel Film Width: |
≤540mm |
Reel Outer Dia.: |
400mm |
Reel Inner Dia.: |
75mm |
Power source: |
AC220V ±10% 50-60HZ 3KW |
Compressed Air: |
0.6MPa, 0.36m3/min |
Advantage:
1) Machine fully controlled by Siemens or Omron PLC & Touch-Screen |
2) Minute capacity can automatically display on Touch screen |
3) Film transport system drived by Panasonic |
4) Safe quick change of tube and collar by just pull out the bracket |
5)Electrical photo sensor inducting color code to control bag length |
6) Unique Pneumatic Film-Reel locking structure to avoid film drawing deflecting |
7)independent temperature adjustment& code printing |
