Design specification:
1. ACPspecification:
Width: 1,220~1,575mm
Thickness: 3.0mm(adopt aluminum coil thickness 0.1~0.5mm)
4.0mm/6.0mm(adopt aluminum coil thickness 0.15~0.6mm)
2.0mm (adopt aluminium coil thickness 0.10~0.15mm)
Length: according to production requirement to set
2. material:
PE coreboard: LDPE( can be the recycled material)
Coated Aluminum coil:
Width: 1,240 ~ 1,600 mm
Thickness: 0.10 ~ 0.50 mm
Weight: 5,000 kg/p
Outer diameter: Φ1200mm(max)
Inner diameter: Φ150mm,Φ405mm,Φ505mm
Macromolecule film:
Width: 1,260 ~ 1,630 mm
Thickness: 30 ~ 50um
Weight: 60 ~ 90 kg/p
Protective film: PE/SOFT
Width: 1,600m
Thickness: 0.1/0.2 mm
Outer diameter: Φ300mm
Inner diameter: Φ75mm
Weight per reel: 60kg
3. production velocity: 1.0 ~ 3.0 m/min
4. production throughput: (calculate as 300 days/year, 20 hours/day)
Width: 1220mm panel 1100,000 square meters/ year
Width: 1575 mm panel 1200,000 square meters/ year
5. electric:
electric source: 3φ-380v-50hz or accodring to buyer's country standard
electric power: 360kw(heating) +220 kw (power). Practical power: 290kw
6. atmospheric pressure source:
pressure: 5 ~ 7 kgf/cm2
gas amount: 0.5 ~ 1 m3/min
7. water amount: ( industrial water )
water pressure: 1 ~ 2 kg/cm2
circulating amount: 0.5 ~ 1 m3/d (recycled)
8. Equipment total weight and square meter:
Equipment total weight: about 90,000 kg
Equipment dimension: about 42,000 L x 94,000 W x 4,100 H (mm)
