Geophysical Drilling Water Well Logging Winch
Negotiable
MOQ: 1 Set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Place of Origin:
Chongqing, China
Brand Name:
Gold
Model Number:
JCH-3
Payment & Shipping
Payment Methods:
Port of Shipment:
China main port
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Hydrological Water Well Logging Instrument, Oil Well Logging MeterNegotiableMOQ: 1 Set -
Automatic Cabe Winding Winch,well Logging Equipment 1000m Geophysical Equipment SuppliersNegotiableMOQ: 1 Set
-
Geophysical Well Logging Winch 1000m Borehole Geophysical Logging EquipmentNegotiableMOQ: 1 Set
-
300m, 500m, 1000m, 2000m Automatic Long Cable Pulling WinchNegotiableMOQ: 1 Set
-
30, 300m, 3000m Bore Hole Logger JGS Bore Hole LoggingNegotiableMOQ: 1 Set
Place of Origin
Chongqing, China
Brand Name
Gold
Model Number
JCH-3
Power Source
Electric
Application
Auto
Geophysical Drilling Water Well Logging Winch
Main Applications and Features
- Adopt advanced frequency conversion technology to control the winch
- Automatic constant speed and manual speed control, automatic overload protection
- Automatic addition and subtraction to calculate the depth, with depth error automatic compensation.
- Use of commercial power or AC power generator
- Self-locking function while winch ascending and descending
- Steady in velocity without jitter in full speed range
Technical Specifications
- Speed Range: 1~29.9 m/min
- Depth Error: ≤0.4‰
- Depth Range: 0~9999.99 m
- Power Supply: AC220V±10% 50Hz ±5%
- Continuous Working Time: ≤24 hr
- Depth Pulse Equivalent: 0.25mm/pulse
- Working Temperature: -10℃~ +70℃
- Volume: 305×200×220mm,
- Weight: <3kg
- Power Consumption: <1.5kW
- Constant Speed Range: 0.5~20m/min, Error: ±10%, ±1 digit
