Deascription:
heat shrinkable busbar sleeve have the outstanding insulation performance, it is used to insulate wires, switchgear & bus bars offering abrasion resistance and environmental protection for conductors, connections, joints and terminals. It is typically placed over the connection to be protected and then heated.
Technical data:
Item |
Indicator |
Hardness |
less than 80 |
Fire resistant: |
Oxygen index more than 30 |
Radial shrinkage |
more than 50% |
Axial shrinkage |
less than 5% |
Tensile strength |
more than12Mpa |
dielectric strength |
more than 25KV/MM |
shrink ratio |
2:1 |
Volume resistivity |
more than 1014Ω.cm |
Operating temkperature |
-50 - +105 degree celsius |
Minimum shrink temperature |
110 degree celsius |
Breakdown elongation |
more than 400% |
Standard color |
Black, Red ,Green ,Yellow |
water absorption |
less than 0.5% |
Sizes: Available in different sizes upon customer's request.
Colors: Available in different colors upon customer's request.
