Specifications
1.PLC Control with touch panel step by Step Instruction2.Stainless steel 304 contact parts
3.Simple,functional,low maintenace
Automatic 520 vertical Form-Fill-Seal packing machine
Model: HT-520
Applications:
It's suitable to use in packing the high accuracy and easy fragile material.
Such as puffy food, crispy rice, jelly, candy, pistachio, apple slices dumpling, chocolate, coffee beans, nuts, pet food, small hardwares, medicine and so on.
Technical parameters:
| Model | 520Vertical Form-Fill-Seal Machine |
| Packing speed | Max 50bags/min |
| Bag-making size | (L)80-350mm (W)80-250mm |
| Film material | BOPP/CPP, BOPP/VMCPP, BOPP/PE, PET/VMPET/PE, PET/AL/PE, NY/PE, PET/PE etc. |
| Filling range | Max 2000ml |
| Max packing film width | 520mm |
| Film thickness | 0.04-0.08mm |
| Air consumption | 0.8Mpa 0.40m3/min |
| Total power/ voltage | 3KW/220V 50-60HZ |
| Outside size | (L)1430x(W)1200x(H)1700mm |
| Gross weight | 680Kg |
Features:
1. Equipped with safety protection, comply with firms safety management requirements.
2. The packing machine use PLC control with stable, reliable biaxial high accuracy output and color touch screen, bag-making, measuring, filling, printing, cutting, finished in one operation.
3. PLC Control with touch panel step by Step Instruction.
4. Pulling belt film draw down system is controlled by servo motor, high precision orientation, size more nicety.
5. Stainless steel 304 contact parts.
6. External film releasing mechanism: simpler and easier installation of packing film.
7. Adjustment of bag deviation just needed to be control the touch screen. Operation is very simple.
8. Close down type mechanism, defending powder into inside of machine.
9. Make pillow bags and hanging bags in terms of customers different requirements.
10. It can finished all processes bag forming, bag sealing, packaging, date printing automatically.
