Help CenterElectronic Load Cell Controller
Related Products
Description:
GS311 is a high performance, high capacity single point load cell designed for direct mounting of large weighing platforms. The rugged construction offers high immunity to side forces making it suitable for a wide range of weighing applications, including bench scales, check weighing and process weighing. A special humidity resistant protective coating assures long term stability over the entire compensated temp. range. GS311 provides scale manufacturers with a high accuracy low cost sensor to meet today’s needs.
Applications: Large platform scales, Hanging scales , Check weighing
Single point 600 x 600mm platform
Description:
GS311 is a high performance, high capacity single point load cell designed for direct mounting of large weighing platforms. The rugged construction offers high immunity to side forces making it suitable for a wide range of weighing applications, including bench scales, check weighing and process weighing. A special humidity resistant protective coating assures long term stability over the entire compensated temp. range. GS311 provides scale manufacturers with a high accuracy low cost sensor to meet today’s needs.
Applications:Large platform scales, Hanging scales , Check weighing
Single point 600 x 600mm platform
Technical Parameter:
Rated Load: |
50/100/150/ 200/250/300/500/ 635kg |
Sensitivity: |
(2.0±0.1%) mV/V |
Combined Error: |
±0.02% F.S |
Creep Error(30min): |
±0.02% F.S |
Zero Balance: |
±1% F.S |
Tco: |
±0.02% F.S/10°C |
Tc Span: |
±0.02% F.S/10°C |
Input Resistance: |
385±5Ω |
Output Resistance: |
351±2Ω |
Insulation Resistance: |
≥5000MΩ |
Operating Temperature Range |
-30~+70°C |
Maximum Safe Over Load: |
150%F.S |
Ultimate Over Load: |
300%F.S |
Recommend Excitation Voltage: |
10~12V DC |
Maximum Excitation Voltage: |
15V DC |
Sealing Class: |
IP66 |
Element Material: |
Alloy Steel, Stainless Steel |
Cable: |
Length=L:1.5m |
Citation: |
GB/T7551-1997/ OIML R60 |
Mode Of Connection: |
Red(Input+),Black(Input-),Green(Output+),White(Output-) |
