Product Characteristics:
GS306 is a precision single-bridge shear beam force transducer designed for use in low profile platform scales and load cell in con-rod conversions of mechanical scales. These transducers are mounted at one end and the load applied to the free end. Application in hoppers, tanks and silos, overhead track scales, engine test stands and dynamometers.
Technical Parameter:
Rated load: |
7t |
Sensitivity: |
(1.75±0.1%) mV/V |
Combined error: |
±0.02% F.S |
Creep Error(30min): |
±0.02% F.S |
Zero balance: |
±1% F.S |
Temp. effect on zero: |
±0.02% F.S/10°C |
Temp. effect on Span: |
±0.02% F.S/10°C |
Input resistance: |
385±5Ω |
Output resistance: |
351±1Ω |
Insulation resistance: |
≥5000MΩ |
Operating Temp. Range |
-30~+70°C |
Maximum safe over load: |
150%F.S |
Ultimate over load: |
300%F.S |
Recommend excitation: |
10~12V DC |
Maximum excitation: |
15V DC |
Sealing Class: |
IP67/IP68 |
Element material: |
Alloy Steel/ Stainless Steel |
Cable: |
Length=L:6m |
Citation: |
GB/T7551-1997/ OIML R60 |
Mode of Connection: |
Red(Input+),Black(Input-),Green(Output+),White(Output-) |
