Load Cell Controller GS312

Name: Load Cell Controller GS312
Brand: GOLDSHINE
SKU: 128763971
Availability: InStock

US$ 36 - 36 MOQ: 20 Pieces

Key Specifications

Get Latest Price

Place of Origin:

Zhejiang, China

Brand Name:

GOLDSHINE

Model Number:

GS312

Contact Supplier Request Quote Chat Now

Ningbo Goldshine Electronic Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Ningbo or Shanghai

Delivery Detail:

Delivery time depends on order quantity.

Product Details
Company Profile
Contact Us

Place of Origin Zhejiang, China

Brand Name GOLDSHINE

Model Number GS312

Usage Pressure Sensor

Theory Resistance Sensor

Output Other, Analog sensor/Digital sensor

Description:

GS312 load cells are available in the capacities 20kg to 300kg. They offer stainless steel construction, complete hermetic sealing, oil proof, waterproof, anti-corrosive gas and medium making them suitable for using in all kinds of environments. Single point parallel beam, suitable for electronic scale, electronic platform scale, belt scale and other electronic weighing devices.

Technical Parameter:

Rated Load:	20/30/50/75/100/200/300kg
Sensitivity:	(2.0±0.1%) mV/V
Combined Error:	±0.03% F.S
Creep Error(30min):	±0.03% F.S
Zero Balance:	±1% F.S
Temp. Effect On Zero:	±0.02% F.S/10°C
Temp. Effect On Span:	±0.02% F.S/10°C
Input Resistance:	385±5Ω
Output Resistance:	353±2Ω
Insulation Resistance:	≥5000MΩ
Operating Temperature Range	-30~+70°C
Maximum Safe Over Load:	150%F.S
Ultimate Over Load:	200%F.S
Recommend Excitation Voltage:	10~12V DC
Maximum Excitation Voltage:	15V DC
Sealing Class:	IP65
Element Material:	Alloy Steel /Stainless Steel
Cable:	Length=L:3m
Citation:	GB/T7551-1997/ OIML R60
Mode Of Connection:	Red(Input+),Black(Input-),Green(Output+),White(Output-)t-)
