Plastic Card Punching Machine---A3

Plastic Card Punching Machine---A3 photo-1
Negotiable MOQ: 1 Set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Condition:
New
Type:
Hydraulic Cutting Machine
Application:
Cut cards
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai
Delivery Detail:
Delivery time depends on order quantity.
Condition New
Type Hydraulic Cutting Machine
Application Cut cards
Place of Origin Jiangsu, China
Brand Name GNT
Model Number GN-CUTTER-A3
Dimensions 840*980*1910mm
Voltage 380V 50/60Hz

Specifications

1.Format: 300*480mm
2.Punching head: 3 heads
3.Punching size: ISO international standard
4.Punching thickness:0.1-1.2mm



Product Description

      Card Punching Machine is controlled through imported PLC. The material feed system adopts the imported servo motor, high-precise ball screw and plane guide imported from Japan in order to ensure smooth moving and accurate moving distance. It uses the high sensitive sensor to read the position marks to ensure accurate and reliable location.
    The hydraulic pump from Taiwan is featuring low noise and large flow. The quality hydraulic valves from Taiwan and the American seals have long service life. The punching mould driven by hydraulic cylinder can work smoothly and reliably with low noise. The punch mould is made with imported Japanese mould steel. Its software function is strong; different cards can be set into different step distances. Punching precision can be ensured even in the situation of material distortion or mechanical abrasion.



Specifications

Format 300*480 mm
ISO CR-80 Templates 3*8 (24-up cards) layout
Punch Heads 3 heads
Speed Output up to 10,000~12,000 cards/hour
Feeding Automatic feed by light eyes read
Punch Method Hydraulic cylinder
Air Supply 0.6MPa
Air Consumption 50L/min
Power Supply AC380V, 50/60Hz
Power 5HP
Machine Weight(Packed) Approximately 1200 KGS
Total Shipping Dimensions (2 crates) H1840 x W980 x H1910 mm H1250 x W560 x H1230 mm
