Specification of the equipment
Selections |
Specifications |
Remarks |
|
WG-STDO-110 |
Item No. |
WG-STDO-110 |
—— |
O2 Flow |
110Nm3/hour |
—— |
|
O2 Purity |
93±2% |
—— |
|
Export Pressure of O2 |
150Bar |
Adjustable |
|
O2 Dew Point |
-45°C |
Atmospheric |
|
Compressed Air Consumption |
1320 Nm3/hour |
6Bar |
|
Mode of operation |
Full automatic |
—— |
|
Specification of key machine
1 Air Compressor
Item |
Atlas Copco Screw Air Compressor
|
|
Item |
GA-132 |
|
Air Output |
≥24Nm3/min |
|
Export Pressure |
≥0.7Mpa |
|
Function |
Provide compressed air.
|
2 O2/N2 Separation System
Item |
Specifications |
Notes |
|
Item |
WG-STDO-110 |
HUILIN |
|
O2 Flow |
110Nm3/h |
Standard |
|
Compressed Air Consumption |
1320Nm3/hour |
Standard |
|
O2 Purity |
93±2% |
-------- |
|
Output Pressure |
4Bar |
Can be adjustment |
|
O2 Dew Point |
-45°C |
Atmospheric |
|
Running Time |
≥8600h/year |
Continuous Work |
|
Equipment Life |
20 years |
zeolite molecular sieve for 10 years. |
3 Oxygen Compressor
Item |
Oxygen Compressor
|
|
Type |
VW-2/41-150 |
|
Oxygen Output |
≥110Nm3/hour |
|
Export Pressure |
≥150Bar |
|
Function |
Provide compressed Oxygen
|
Technical Features
1). Full Automation
All systems are designed for un-attended operation and automatic Oxygen demand adjustment.
2). Lower Space Requirement
The design and Instrument makes the plant size very compact, assembly on skids, prefabricated from factory.
3). Fast Start-up
Start-up time is only 5 minutes to get desired Oxygen purity. So these units can be switched ON&OFF as per Oxygen demand changes.
4). High Reliabiity
Very reliable for continuous and steady operation with constant Oxygen purity. Plant availability time is better than 99% always.
5). Molecular Sieves life
Expected Molecular sieves life is around 15-years i. E. Whole life time of Oxygen plant. So no replacement costs.
6). Adjustable
By altering flow, you can deliver nitrogen with precisely the right purity.
Oxygen Generator Applications
Paper and Pulp industries
Glass industries
Metallurgical industries
Chemical industries
Water and Wastewater treatment
Fish farming
