HighTek USB to RS485 adapter with RJ45 interface usb to RJ45 details:
Performance parameters
1. Standards: conforming to USBV1.1 and 1.0, EIA RS-485 and RS-422, backwards compatible.
2. USB signals: VCC DATA+ DATA- GND FG
3. RS-485 signals: T+, T-, GND.
4. RS-422 signals: T+, T-, R+, R-, GND.
5. Industrial grade, master chipset UK FTDI FT232;
6. Working modes: asynchronous, point-to-point or point-to-multipoint, 2-line half duplex and 4-line full duplex.
7. Direction control: adoption of automatic data stream control for automatic recognition and control of data transmission direction.
8. Baud rate: 300-4608000bps, automatic detection of the transmission rate of the serial interface signal.
9. Workload ability: point-to-multipoint supported a maximum of 32 RS-422 or RS-485 interface equipment is supported.
10. Transmission distance: 1200 meters for RS-485/422 end (when 9,600bps) and a maximum of 5 meters for USB.
11. Interface protection: 600W lightning strike and surge protection and 5KV electrostatic protection.
12. Interface forms: A interface male connector, RJ-45 and USB end.
13. Working environment: -40 to 85 degree C, relative humidity 5% to 95%.
14. Transmission distance: 0-1200meters (128,000bps-9,600bps)
15. Windows95/98/2000/XP/Vista/Win7/Win8/Linux and IMAG are supported.
Connector and signal
RS-485/RS-422 output signals and PIN assignment
|
DB9 Connector (PIN) |
Output Signal | RS-422 Full Duplex Cabling | RS-485 Halfduplex cabling |
| 1 | T/R+ | Sending(A+) | RS-485(A+) |
| 2 | T/R - | Sending(B-) | RS-485(B-) |
| 3 | RXD+ | Receiving(A+) | Null |
| 4 | Receiving(B-) | Null | |
| 5 | |||
| 6 | RXD- | ||
| 7 | N/A | ||
| 8 | GND | ||
| 9 | N/A |
