Multimode 2km 10-100M SC Interface Economical Fiber Optic Transceiver

Indicator

Status

Description

FX Link/Act

Light

Link connection status indicator light, bright light indicates link connectivity

Flash

Link activity status indicator light, flashing indicates FX client has data packets

TX Link/Act

Light

Electrical link status indication light indicates power link connectivity

Flash

Electrical link activity status indicator, flashing indicates TX packets through the end there

FDX

Light

Said transceiver operates in full-duplex mode

Dark

Said transceiver operates in half-duplex mode

PWR

Light

Indicates that the power is turned on, the power supply is normal

FX100

Light

Said optical interface transfer rate of 100M

TX100

Light

Said electrical interface transfer rate of 100M

Dark

Said electrical interface transfer rate of 10M

Model

Optical wavelength

(nm)

Optical power

(dbm)

Sensitivity

(dbm)

Transmission distance

(Km)

HK-9001

1310

-19~ -14

<-31

2
