The solid float PVC boom is the important equipment used for preventing spilled oil on waters from diffusion and transfer. It is widely used for long-term deployment on waters such as open seas, bays, harbors, wharfs, rivers, oil platform, oil-refining plants, oil piers, oil storage and also for emergent use in oil spilling accidents
Features
- 1. Made of the high strength fabric coated PVC on its two sides, having excellent resistance to oil and ageing.
- 2. The solid float have a large capacity of buoyancy and excellent wave and steadiness
- 3. The boom body is provided with a pulling rope, a strengthening ribbon and tensile ballast chains serving as elements to withstand forces and has tensile strength
Technical data
|
Model Parameter |
WGV600 |
WGV700 |
WGV750 |
WGV800 |
WGV900 |
WGV1000 |
WGV1100 |
Overall height(mm) |
600 |
700 |
750 |
800 |
900 |
1000 |
1100 |
Freeboard(mm) |
150 |
210 |
260 |
280 |
320 |
340 |
370 |
Draft(mm) |
380 |
390 |
400 |
420 |
490 |
540 |
560 |
Max, working tensile strength(mm) |
20 |
25 |
30 |
45 |
55 |
75 |
85 |
Length per section (m) |
20 |
||||||
Max, wave height to withstand(m) |
0.5 |
0.5 |
1 |
1.5 |
1.8 |
2 |
2 |
Max, wind speed to withstand(m/s) |
8 |
10 |
10 |
15 |
15 |
18 |
20 |
Max, current speed to with stand(KN) |
1 |
1 |
1.5 |
1.5 |
2 |
2.5 |
2.5 |
Standard connector |
ASTM or Stainless steel hinge or pin |
ASTM or Stainless steel hinge or pin |
ASTM or Stainless steel hinge or pin |
ASTM or Stainless steel hinge or pin |
ASTM or Stainless steel hinge or pin |
ASTM or Stainless steel hinge or pin |
ASTM or Stainless steel hinge or pin |
packing dimensions for 20m(m) |
1x1x0.6 |
1.2x1x1 |
1.2x1x1 |
1.3x1.1x1.1 |
1.4x1.5x1.2 |
1.4x1.6x1.3 |
1.4x1.7x1.4 |
