Specifications
QTJ4-40 brick block making machine:Semi automatic
IS09001-2008
Small scale
With CE & BV
QTJ4-40 cement concrete brick block making machine in Chile
………………………………………………………………………………………………………………
1. Our Advantages |
|
→ We are brick and block making machine manufacturer with 40 years professional experience. → We can offer large scale, millde scale and small scale brick and block making machine. → We have more than 40,000 square meters production area with over 200 workers. → Welcome to visit Shenta factory. |
………………………………………………………………………………………………………………
2. Characteristics
1 |
QTJ4-40 is the semi-automatic brick machine to meet the market demand, it is all mechanical transmission, automatic pallet load and concrete load, has the advantage of compact structure, reliable operation, very low malfunction rate, and easy maintenance and transportation, utilize the mould vibration technology to form the excellent shape, dense frame and high compressive strength brick, with fewer cement consumption. |
2 |
By changing different mold, the QTJ4-40 can produce different wall brick, porous brick and cement solid brick, it can meet the brick requirement of small construction engineering, is the best selection of small scale brick factory or mobile brick factory. |
………………………………………………………………………………………………………………
3. Specifications
Outside Dimension (mm) |
3100x1530x2380 |
Operation Cycle (s) |
40-50 |
Main Machine Weight (Ton) |
2.5 |
Vibration Frequency (rpm) |
4300 |
Power Consumption (Kw) |
16.5 |
Vibration Force (Kn) |
30 |
Pallet Dimension (mm) |
840x450x60 |
Vibration Power (kW) |
9 |
………………………………………………………………………………………………………………
4. Prouduce Capacity
Brick Size |
Blocks/Mould |
Blocks/Hour |
Blocks/Shift |
Remark |
Hollow Brick (400x200x200mm) |
3 |
216~270 |
1,700~2,100 |
|
Hollow Brick (400x150x200mm) |
5 |
360~450 |
2,900~3,600 |
|
Hollow Brick (400x100x200mm) |
7 |
500~630 |
4,000~5,000 |
|
Hollow Brick (390x190x190mm) |
5 |
360~450 |
2,900~3,600 |
|
Porous Brick (240x115x90mm) |
9 |
650~810 |
5,200~6,500 |
|
Solid Brick (240x53x115mm) |
21 |
1,510~1,890 |
12,000~15,000 |
|
Interlock Brick (225x112x60mm) |
12 |
860~1,080 |
6,900~8,600 |
………………………………………………………………………………………………………………
5. Production Line
………………………………………………………………………………………………………………
6. Raw Materials |
|
Ⅰ.Cement—12%; Ⅱ. Fly ash or refine stone powder or refine sand—38%; Ⅲ. Crushed stone (diameter<15mm)—50% Materials such as sand, crushed stone, cement, dust and fly coal ash, cinder, gravel, perlite, wet ash in power plant, dry ash, hybrid ash, boiler slag, spontaneous combustion coal gangue, mountain flour, haydite, mine tailings, scoria, steel slag, carbide slag, water-granulated slag, wind-granulared slag, dry slag, smelting slag, sulfuric acid residue, phosphate fertilizer slag, caustic sludge, laterite in aluminum manufacturers, electrolytic copper slag, stonework waste, potsherd, waste brick power, construction waste, etc(among which one or two kinds are enough) |
………………………………………………………………………………………………………………
7. Produce Brick and Block |
Shenta machine can produce: various types of concrete brick and block, cement brick and block, standard bricks, perforated bricks and paving bricks, solid/hollow/cellular masonry brick and block, paving stones with or without face mix, garden and landscaping products. slab, edger, kerbstone, grass blocks, solpe blocks, interlocking blocks. These products are of good quality, high compression strength and accurate dimension. Besides, more kinds can be produced such as paving bricks, color grassland bricks and curb bricks if the second raw materials feeding system is added to the line. Widely used in building, road paving, squares, gardens, landscaping. city constructions etc. |
………………………………………………………………………………………………………………
8. Brick and Block Prouduce Site
……………………………………………………………………………………………………………
9. Exhibition
………………………………………………………………………………………………………………
10. Shenta Profile |
|
Shenta Machinery Equipment Co.,Ltd. (short for Shenta machine), we are specialized in concrete brick and block making machine in China, as the most earliest and professional in cement brick and block making machine since1973, we can offer you the brick & block making machine and production line with reliable quality, professional technology, and sincere service. We have exported to Southeast asia, Africa, and Ocenaia, etc.
|
………………………………………………………………………………………………………………
Welcome to visit Shenta machine, and building the solid future for you.
Pre-sale:
Analyze the customer’s need and factory layout design, confirm scale of operation;
Select the fitting choice;
Provide perfect solution to set up a factory.
Sales:
Help to set up the factory;
Provide free service of installation and commissioning;
Provide training for operator and maintenance person.
After-sale:
Help customers to establish production craft formula;
Provide the consultation all the time;
Supply moulds and parts all the time.
Thank you for your attention to SHENTA MACHINE.
Welcome to inquire more information of QTJ4-40 block making machine in Chile
Your inquiry will be highly appreciated.
