QTJ4-60 Manual cement burning-free brick machine price
- 500 Set / Sets per Month
- Fangcheg Guangzhou Shenzhen Shanghai or other China port
- T/T L/C D/P D/A Credit Card PayPal
- QTJ4-60 hand operate concrete brick wall building machine
- Machinery on alibaba website. QTJ4-60 concrete manual block making machine
- low investment QTJ4-60 small scale mesin batako pres
- manual small brick moulding machine QTJ4-60
- Easy operation movable used concrete block making machine for sale
- Movable high quality used concrete block making machine for sale
Product Details
Condition: | New | Type: | Hollow Block Making Machine | Brick Raw Material: | Concrete |
Processing: | Brick Molding Machine | Method: | Other, Platform Vibration | Automatic: | No |
Capacity: | 1920-10080 PCS/shift | Place of Origin: | Guangxi, China | Brand Name: | SHENTA |
Model Number: | QTJ4-60 | Voltage: | 380V | Power: | 7.5KW |
Dimension(L*W*H): | 1365*900*1675mm | Certification: | IS09001 & CE & BV, CE, ISO, BV | Warranty: | 1 year |
After-sales Service Provided: | Engineers available to service machinery overseas |
Packaging Details
Standard seaworthy packing suitable for sea long distance transportation
Product Description
1.Characteristic of manual cement burning-free brick machine
1. QTJ4-60 cement burning-free brick machine is the semi-automatic brick machine which we design & develop to meet the market demand, it is all mechanical transmission, has the features of compact structure, reliable operation, easy maintenance and low failure rate, it utilize the table vibration method to form the brick with excellent shape, dense frame and high strength, as well as lower cement comsumption.
2. By changing different forming mold, the QTJ4-60 cement burning-free brick machine can produce different wall brick, hollow brick, solid brick, paver brick and so on, it is the best solution of the small construction engineering or the middle-small scale brick factory.
Main Specification of manual cement burning-free brick machine
Operation Cycle (s) | 60~80 |
Vibration Force (Kn)
| 20 |
Brick Height(mm) | 60~200 | MainPower Capacity(Kw) | 7.5 |
Vibration Frequency (rpm) | 4300 |
Pallet Dimension (mm)
|
840x450x60
|
Net Weight (Ton) | 1 | Main Machine Dimension(mm) | 1365*900*1675 |
Power Source | 3Phase, 380V/50Hz (Special voltage & frequency is available according to your local power source.) |
Theoretic Productivity of manual cement burning-free brick machine
Brick Type | Dimension | Blocks/Cycle | Blocks/Hour | Blocks/Shift | Remark |
Hollow Brick | 390*190*190mm | 4 | 240 | 1920 | |
Porous Brick | 240*115*90mm | 9 | 540 | 4320 | |
Solid Brick | 240*115*53mm | 21 | 1890 | 10080 |
Note: Special brick model is available according to customer demand.
2. Advantage of manual cement burning-free brick machine
1. Automatic pallet and concrete feeding, it can save manpower and reduce the labor intensity, increase the forming speed and enhance the working efficiency;
3. Raw Material for manual cement burning-free brick machine
Our machine can adopt the following raw materials to make the good quality hollow brick, solid brick
and paver brick.
1.Sand: 30~40%; 2.Fly Ash or Additive: 0 ~10%;
3.Cement: 10~20%; 4.Crushed Stone (<5cm): 30~40%;
5.Construction Refuse or Mineral Slag.
4.Brick Sample
Our machine can produce the concrete hollow brick, solid brick, porous brick, paver brick, interlock brick, road traffic stone and so on.
5.Production flow of manual cement burning-free brick machine
Experienced in selling concrete brick machine to more than 30 different countries, we pack and load the machines well and prevent any damages during transportation, all the key parts are protect by the wooden
box.
Factory Ability:
1.Factory Area: 40,000 square meter;
2.Facility: CNC Lathe: 06 sets; Boring Lathe: 02 sets; Shaper: 02 sets; Milling Machine: 04 sets;
Press Brake: 02 units, CNC Flame Cutter: 01 set; Crane: 10 sets; Shot Blast Machine: 01 set.
Quality Control:
We adopt the high quality steel materials, and every process will have the strict inspection and test
to ensure the machine has perfect performance.
Certification:
Exhibitions:
We take parts in many exhibitions every year, such as Canton Fair in Guangzhou; India international engineering machinery, building materials machinery, mining machinery, engineering vehicles and
parts exhibition; International concrete technology and equipment exhibition in India; The ASEAN-China
Exposition in Nanning, etc.
Pre-sale:
Analyze the customer’s need and factory layout design, confirm scale of operation;
Select the fitting choice;
Provide perfect solution to set up a factory.
Sales:
Help to set up the factory;
Provide free service of installation and commissioning;
Provide training for operator and maintenance person.
After-sale:
Help customers to establish production craft formula;
Provide the consultation all the time;
Supply moulds and parts all the time.
Company Profile
Nanning SHENTA Machinery Equipment Co., Ltd, established in 1973, is the earliest professional and leading manufacturer of concrete block making machinery. After decades of hard working, we have developed into the high-tech enterprises which integrate the research & development, manufacturing, sales and service. SHENTA factory covers an area of 40,000 square meter, with senior engineers more than 20 people and all kinds of technician more than 200 staff. With an annual production capacity of 500 sets.
SHENTA devoted great care to market planning and development, we have earned ISO9001-2008 Quality Management Certificate in 2008, and awarded the title of "valuing contract and keeping promise" for many years. With the advanced technique, sophisticated technology, strict supervision and perfect service, SHENTA has become the high quality supplier in new building material field.
SHENTA not only distributed in all around China, but also exported to Southeast Asia, Africa, and Oceania etc.
Adhering to the philosophy of "Credit & Honest, dedication & devotion, pragmatism & practice, Innovation & Creation", SHENTA stride forward to construction equipment enterprise of specialization, scale and internationalization, provide strong support of equipment for the new building material, building the solid future for you.
