QTY8-15 automatic cinder block machine
1.Characteristic of QTY8-15 automatic cinder block machine 1.Control system: Adopt intelligent programmable logic controller (PLC) and high performance touch screen. Realize the man-machine conversation and fully automatic intelligent operation.
2.High efficient vibration system: Adopt intelligent control technique in the frequency conversion vibration system, distribute materials
in low frequency and form the bricks in high frequency. Moreover, with the synchronous vertical vibration technology, the brick forming
speed becomes faster and the bricks are more compacted.
3.Transmission system: Adopt fully hydraulic transmission, four pillars oriented and synchronous mechanism. Machine operation is stable,
precise and less malfunctions.
4.Feeding system: Adopt the forced advanced rotating arch breaker. It is suitable for various materials, and the process is uniform and quick.
5.Machinery Manufacturing: Made of high strength steels according to the national standard. Special welding techniques and advanced mechanical
working processes bring high precision, durable and a long service life.
Specifications of QTY8-15 automatic cinder block machine
Outside Dimension (mm) |
5200x1900x2800 |
Operation Cycle (s) |
15~25 |
Main Machine Weight (Ton) |
9 |
Vibration Frequency (rpm) |
4300 |
Power Consumption (Kw) |
45.2 |
Vibration Force (Kn) |
100 |
Pallet Dimension (mm) |
900x900x25 |
Vibration Power (kW) |
22 |
Operator quantity |
5 people |
Land required |
5000m2 |
Prouduce Capacity of QTY8-15 automatic cinder block machine
Brick Size |
Blocks/Mould |
Blocks/Hour |
Blocks/Shift |
Hollow Brick (400x200x200mm) |
8 |
1,150~1,920 |
9,200~15,300 |
Hollow Brick (400x150x200mm) |
10 |
1,440~2,400 |
11,500~19,200 |
Porous Brick (240x115x90mm) |
18 |
2,600~4,320 |
20,700~34,500 |
Solid Brick (240x53x115mm) |
36 |
6,480~8,640 |
52,000~69,000 |
Interlock Brick (225x112x60mm) |
21 |
3,000~5,000 |
24,000~40,000 |
Pavers Brick (200x100x60mm) |
21 |
3,000~5,000 |
24,000~40,000 |
Remark: The production capacity data are theoretical and are dependent on machine settings, mix design,aggregates used and other environmental conditions.
3.Brick Samples of QTY8-15 automatic cinder block machine
By changing different molds, the QTY8-15 automatic cinder block machine can produce different type of bricks.
4.Production Line of QTY8-15 automatic cinder block machine
3)All necessary document and drawing and video for free
7.Our Advantages
1)We are brick and block making machine manufacturer with 40 years professional experience.
2) We can offer large scale, millde scale and small scale brick and block making machine.
3) We have more than 40,000 square meters production area with over 200 workers.
4)Welcome to visit Shenta factory
8.Certification
We adopt the high quality steel materials, and every processe will have the strict inspection and
test to ensure the machine has perfect performance.
cess
9.Exhibition
We take parts in many exhibitions every year, such as Canton Fair in Guangzhou; India international engineering machinery, building materials machinery, mining machinery, International concrete technology and equipment exhibition in India; The ASEAN-China Exposition in Nanning, etc.
My dear friends, if you have any questions about automatic cinder block machine, please feel free to contact Alice:)
