Specifications
1. Concrete Mixer;2. High efficiency;
3. Low power consumption;
4. Easy cleaning & maintenance;
5. Long working life
Good Stability & High Efficiency JS500 concrete mixer
......................................................................................................................................................................................................................................
1.Characteristic of JS500 concrete mixer :
HZS Series concrete mixing plant is a modular, quickly-installed concrete mixing plant designed by our company according to market requirement. The aggregate is fed by loader, supplied by batcher and mixed by twin horizontal shafts compulsory mixer. The cement is stored in silo, conveyed by screw conveyor and weighed by cement scale. The water is supplied by water pump and weighted by water scale. The whole procedure is done and controlled by electric control system automatically. It has the function of matching memory, freefall correction, separated manual operation etc, which can realize mode of both manual and automatic operation.
This series of product has the features of simple structure, convenient installation, low cost and advanced configuration. It suits to industry or civil construction, road, bridge and other at site concrete mixing or commercial concrete mixing.
2.Feature of JS500 concrete mixer :
JS series mortar mixer is horizontal type twin-shaft compulsory mixer, apply to various middle-small scale prefabricate construction plant and road, bridge, water engineering, port, dock and other industry or civil architecture, it can mix the stiff concrete, plastic concrete, pasty concrete, light aggregate concrete and other mortar. It Not only be operated independently but also can compound to a simple mixing plant with the HP series aggregated batcher.
3.Specification of JS500 concrete mixer :
|
Model |
Loading Capacity |
Discharging Capacity |
Productivity |
Max. Grain Size |
Mixing Motor Power |
Machine Weight |
JS-500 |
800 (L) |
500 (L) |
≥25 (m3/h) |
60 (mm) |
18.5 (Kw) |
4(Ton) |
JS-750 |
1200 (L) |
750 (L) |
≥35 (m3/h) |
60 (mm) |
30 (Kw) |
6.5 (Ton) |
JS-1000 |
1500 (L) |
1000 (L) |
≥50 (m3/h) |
60 (mm) |
2X18.5 (Kw) |
9 (Ton) |
JS-1500 |
2400 (L) |
1500 (L) |
≥75 (m3/h) |
60 (mm) |
2X22 (Kw) |
11.5 (Ton) |
4.The Detail of JS500 concrete mixer :
5. About SHENTA Machine:
Nanning SHENTA Machinery Equipment Co., Ltd, lies at the beautiful “Green City of China” – Guangxi Nanning, is one of the first group of the manufacturer specialized in research, development, fabrication of the concrete block machine, mixing machine and other construction material machine in China, pass the ISO 9001:2008 Certificate. We uphold the philosophy “advanced technology, nice craft, strict supervision and perfect service”, provide customer the excellent and reliable equipments for the new and eco-friendly construction material industry.
SHENTA Machine locate in the south of China, far from the frontier of Vietnam only 200km, is the closest Brick Machine Manufacture from ASEAN, with the advantageous geographical location and transportation, we build the solid foundation with the ASEAN country to develop the long-term and stable cooperation.
SHENTA Machine’s plant occupy 40,000m2 area, include 20,000m2 workshop, 210 workers team, 20 administrators and 15 technicians, produce the brick production lines and machine more than 500 units per annum, sell in domestic and export to South-east Asia, USA, Afric and Middle East region.
6.Our Advantages:
→ We are brick and block making machine manufacturer with 40 years professional experience.
→ We can offer large scale, millde scale and small scale brick and block making machine.
→ We have more than 40,000 square meters production area with over 200 workers.
→ Welcome to visit Shenta factory.
Welcome Contact Maky (Skype: Shenta_maky, Mobile: +86.13788113588) for more information
and specification of the JS500 concrete mixer
