Concrete paving machine QTJ4-18 automatic block brick making machine
- 1000 Set / Sets per Month
- Shenzhen Guangzhou Shanghai Fangchenggang or other port
- T/T L/C D/P D/A Credit Card PayPal
- Fully automatic QTJ5-20 cement block machine coal ash brick making machine
- hot sale! QTJ5-20 Automatic mechanical concrete curbing machine
- QTY6-15 fully automatic hydraform brick making machine in south africa
- QTJ5-20 automatic cement vibro press brick manufacturing machine
- Construction equipment for sale QTJ4-18 automatic cement block making machine
- QTJ5-20 fly ash hollow bricks machine indian price
Product Details
Condition: | New | Type: | Hollow Block Making Machine | Brick Raw Material: | Concrete |
Processing: | Brick Molding Machine | Method: | Other, Vibration Forming | Automatic: | Yes |
Capacity: | 19200-86400pcs/8hrs | Place of Origin: | Guangxi, China | Brand Name: | SHENTA MACHINE |
Model Number: | QTJ4-18 | Voltage: | 380V/3Phase/50HZ | Power: | 37Kw |
Dimension(L*W*H): | 3400x2000x4300mm | Certification: | ISO901:2008, CE, BV, ect. | Warranty: | 12 months |
After-sales Service Provided: | Engineers available to service machinery overseas |
Packaging Details
20GP/40GP/40HQ container, according to the customer's request, seaworthy packing
Product Description
Concrete paving machine, QTJ4-18 automatic block brick making machine
Characteristic of QTJ4-18 concrete paving machine
- Full mechanical transmission with feature of compact structure and reasonable design.
- Adopt high quality and intelligent PLC controller, HMI operates and brick automatically output, automatically reset, lack material and lack plank alarm, easy and humanized operation is more safety and reliable.
- The block making machine utilize high frequency vibration to mold the brick, thefinished product is more dense and solid.
- The high speed arch breaking device can consumedly shorten the material distributing time.
- Minimum 05 workers to operate the production line.
- The mixer is included in QTJ4-18 host block machine.
Technical Specification of QTJ4-18 concrete paving machine
Outside Dimension (mm) | 3400x2040x4300 | Operation Cycle (s) | 18-25 |
Main Machine Weight (Ton) | 7 | Vibration Frequency (rpm) | 4300 |
Power Consumption (Kw) | 37 | Vibration Force (Kn) | 45 |
Pallet Dimension (mm) | 840x450x30 | Vibration Power (kW) | 11 |
Operator quantity | 4 people | Land required | 3000m² |
Theoretical Productivity
Brick Size | Blocks/Mould | Blocks/Hour | Blocks/Shift |
Hollow Brick (400x200x200mm) | 3 | 430~600 | 3,500~4,800 |
Hollow Brick (400x150x200mm) | 5 | 720~1,000 | 5,800~8,000 |
Hollow Brick (400x100x200mm) | 7 | 1,000~1,400 | 8,000~11,200 |
Hollow Brick (390x190x190mm) | 4 | 580~720 | 4,600~5,700 |
Porous Brick (240x115x90mm) | 9 | 1,300~1,800 | 10,400~14,400 |
Solid Brick (240x53x115mm) | 21 | 3,000~4,200 | 24,000~33,600 |
Interlock Brick (225x112x60mm) | 12 | 1,700~2,400 | 13,800~19,200 |
Production Process of QTJ4-18 concrete paving machine
Production Line Layout of QTJ4-18 concrete paving machine
Brick Production process by using QTJ4-18 concrete paving machine
Brick Raw Material
Many kinds of materials such as concrete, cement, sand, crushed stone, dust and fly coal ash,
cinder, gravel, perlite, construction refuse, etc. can be used to make brick.
Brick Samples
Various types of concrete block, cement brick, solid brick, hollow block, perforated brick, paving brick,
interlocking block, building brick, garden and landscaping block, grass block, slope block, etc. can be made.
Brick Moulds
Brick Plant of QTJ4-18 concrete paving machine
Exhibition Show
Company Information
Pre-sale:
Analyze the customer’s need and factory layout design, confirm scale of operation;
Select the fitting choice;
Provide perfect solution to set up a factory.
Sales:
Help to set up the factory;
Provide free service of installation and commissioning;
Provide training for operator and maintenance person.
After-sale:
Help customers to establish production craft formula;
Provide the consultation all the time;
Supply moulds and parts all the time.
Buying tips:
We are involving in small scale, medium scale, large scale brick and block making machine.
when you want to buy, please tell me:
1) Your bricks size ( length, width and height);
2) Your bricks pricture(If you have);
3) Your production request per day.
Thank you for your attention to SHENTA MACHINE.
Welcome to inquire more information of QTJ4-18 concrete paving machine.
Your inquiry will be highly appreciated.
Company Profile
Nanning SHENTA Machinery Equipment Co., Ltd, established in 1973, is the earliest professional and leading manufacturer of concrete block making machinery. After decades of hard working, we have developed into the high-tech enterprises which integrate the research & development, manufacturing, sales and service. SHENTA factory covers an area of 40,000 square meter, with senior engineers more than 20 people and all kinds of technician more than 200 staff. With an annual production capacity of 500 sets.
SHENTA devoted great care to market planning and development, we have earned ISO9001-2008 Quality Management Certificate in 2008, and awarded the title of "valuing contract and keeping promise" for many years. With the advanced technique, sophisticated technology, strict supervision and perfect service, SHENTA has become the high quality supplier in new building material field.
SHENTA not only distributed in all around China, but also exported to Southeast Asia, Africa, and Oceania etc.
Adhering to the philosophy of "Credit & Honest, dedication & devotion, pragmatism & practice, Innovation & Creation", SHENTA stride forward to construction equipment enterprise of specialization, scale and internationalization, provide strong support of equipment for the new building material, building the solid future for you.
