Specifications
cheap brick making machinesMechanical transmission
stable operation
Compact structure small occupation
PLC control
hot sale in china !!! QTJ5-20 production line
I. Characteristic of QTJ5-20 brick making machine price cheap brick making machines
- Control system: Adopted with Taiwan intelligent programmable logic controller (PLC) and high performance LCD, our brick machines can realize the man-machine conversation and fully automatic intelligent operation.
- High efficient vibration system: Adopt intelligent control and synchronous vertical vibration techniques. Bricks formed by synchronous vibrations of press head and mould table, which makes the forming speed faster and the bricks denser.
- Machinery Manufacturing: Made of high strength steels according to the national standard. Special welding techniques and advanced mechanical working processes bring high precision, durable and a long service life.
- Transmission system: Adopted with mechanical transmission and two pillars oriented. Simple and compact structure brings it stable and consecutive actions and easy to be maintained.
- Feeding system: Adopt the forced advanced rotating arch breaker. It is suitable for various materials, and the process is uniform and quick.
Operation Cycle |
20~25s |
Pallet Size |
1050*550*30mm |
Brick Height |
60~200mm |
MainPower Capacity |
44Kw |
Mixer Model |
JS350 |
Vibration Force |
60kN |
Net Weight |
8t |
Main Machine Dimension |
3400*2040*4300mm |
Power Source |
3Phase, 380V/50Hz (Special voltage & frequency is available according to your local power source.) |
||
Brick Type |
Dimension |
Blocks/Cycle |
Blocks/Hour |
Blocks/Shift |
Remark |
Hollow Brick |
390*190*190mm |
5 |
900 |
7,200 |
|
Porous Brick |
240*115*90mm |
16 |
2,880 |
23,040 |
|
|
Paver Brick (Non-color) |
200*100*60mm |
18 |
3,240 |
25,920 |
|
Solid Brick |
240*115*53mm |
32 |
5,760 |
46,080 |
|
Note: Special brick model is available according to customer demand.
V. Process Flow: QTJ5-20 brick making machine price cheap brick making machines
VI. Raw Material: QTJ5-20 brick making machine price cheap brick making machines
Our machine can adopt the following raw materials to make the good quality hollow brick, solid brick and paver brick.
Our machine can produce the concrete hollow brick, solid brick, porous brick, paver brick, interlock brick, road traffic stone and so on.
Experienced in selling concrete brick machine to more than 30 different countries, we pack and load the machines well and prevent any damages during transportation, all the key parts are protected by wooden boxes.
I. Factory Ability:
CNC Lathe |
06 sets |
Boring Lathe |
02 sets |
Shaper |
02 sets |
Milling Machine |
04 sets |
Press Brake |
02 sets |
CNC Flame Cutter |
01 set
|
Crane |
10 sets |
Shot Blast Machine |
01 set |
X-ray Inspection Instrument |
01 set |
We adopt the high quality steel materials, and every process will have the strict inspection and test comply with the ISO-9001or CE standard to ensure the machine has perfect performance.
our company
Until now we have successfully export and handover our brick machine and production line to customers in Vietnam, Indonesia, Angola, India and Papua New Guinea, and acquire the good reputation of user.
We take parts in many exhibitions every year, such as Canton Fair in Guangzhou; Bauma China in Shanghai, India international engineering machinery, building materials machinery, mining machinery, engineering vehicles and parts exhibition; International concrete technology and equipment exhibition in India; The ASEAN-China Exposition in Nanning, etc.
