The machine adopt semi-closed structure for easy matainance
suitable for closing filled bags and sacks made of cotton,jute,plastic,and paper etc.
Model Item |
GK35-2C |
GK35-6A |
Max..speed | 1900 rpm | |
Working Speed | 1700rpm | |
Thickness of material | 8mm | |
Range of Stitch Width | 6.5-11mm | |
Stitch Type | Double thread chain stitch | |
Thread Type | 20/6,20/9 synthetic fiber thread or cotton thread | |
Needle | Model 80800 200-250# | |
Pulley | Φ114mm | |
Thread chain cutter | Manual operated | Electro-pneumatic operated |
Motor | Common motor | Brake motor |
Motor power | 370w | |
Weight | 27kgs | 30kgs |
Size(L*W*H) | 350×215×440(mm) | 350×240×440(mm) |
Equipped with braided knife moving back and forward. After sealing the bag ,you could push the line into the needle plate opening groove, the cutter automatically cut off. you could start and stop the machine by manually.
Start and stop of the machine are oparated by manual(foot pedal )
