Network FTP Cat5e BC /CCA/CCS
US$ 50 - 50
MOQ: 1 Box
Key Specifications
Get Latest Price
Brand Name:
Superlink Cable
Model Number:
Cat5e FTP/SFTP
Conductor Material:
Copper
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai Ningbo or Shekou
Delivery Detail:
Delivery time depends on order quantity.
Related Products
Brand Name
Superlink Cable
Model Number
Cat5e FTP/SFTP
Conductor Material
Copper
Insulation Material
PE
Jacket
PVC
Number of Conductors
4 Cores
Application
Network
Specifications
Application structured cabling for computer networks such as Ethernet over twisted pair.CAT5 cable support 10/100 Ethernet.
- Product testing is using MEA network analyzer that imported from Germany.
| Model | cat5e FTP cable |
| Conductor Size | 24AWG |
| 4*2*1/0.51/0.5/0.49/0.48mm | |
| Conductor Material | BC/CCU/CCA/OFC/CCS |
| Nuber Of Conductor | 2P, 4P |
| Shiled | UTP/FTP/STP/SFTP /SSTP |
| Flammability Grade: | CMX,CM,MP,CMG,MPG,CMR,MPR |
| Indoor / Outdoor | Single jacket / Double jacket |
| Insulation Material | PE , HDPE |
| Insulation Thickness | 0.55mm |
Number of pairs: 4 pairs |
Pair1: Orange/White Orange Pair2: Blue/ White Blue Pair3: Green/ White Green Pair4: Brown/White Brown |
| Jacket Material | PVC, ROHS PVC, LSZH PVC |
| Jacket Thickness | 0.92-0.95mm |
| DC Resistance(Max.) | 9.5Ω/100m |
| DC Resistance Imbalance | 2.50% |
| Working Capacitance(Max.) | 5.4nF/100m |
| Insulation Resistance | 10000MΩ.km |
| Transmission Velocity | 65% |
| Operating Temperation | -20 °C - +75 °C |
| PVC Jacket Color | As client’s request. |
| Print Words On Cable | CAT5E 4P 24AWG VERIFIED TO EIA/TIA 568B.ISO/IEC 11801 EN501 or clients' request. |
