UL Certified Standard Rg6 Coaxial Cable

UL Certified Standard Rg6 Coaxial Cable thumbnail-1
UL Certified Standard Rg6 Coaxial Cable photo-1
US$ 0.001 - 0.5 MOQ: 10 Kilometers
Key Specifications
Get Latest Price
Place of Origin:
Zhejiang, China
Brand Name:
superlink
Model Number:
rg6-sp238
Contact Supplier Request Quote Chat Now
Hangzhou Super Link Cable Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
shanghai or ningbo
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Zhejiang, China
Brand Name superlink
Model Number rg6-sp238
Type Coaxial
Number of Conductors 1

Specifications

UL certified standard rg6 coaxial cable
(1)1.02CU+FPE+shield+jacket
(1) CE ISO Rosh UL
(2) Factory price
(3) Good service

UL certified standard rg6 coaxial cable





CENTER CONDUCTOR:

1.02 mm BARE COPPER



DIELECTRIC:

GAS  EXPANDED POLYETHYLENE

NOMINAL DIAMETER OVER DIELECTRIC: 4.8 mm



SHIELD:

1ST SHIELD: LAMINATED ALUMINUM TAPE BONDED TO THE DIELECTRIC

2nd SHIELD: ALUMINUM BRAID WIRE 40% - 90% COVERAGE



JACKET:

PVC JACKET

NOMINAL DIAMETER OVER JACKET: 7.2mm

NOMINAL JACKET THICKNESS: 0.76 mm



ELECTRICAL PROPERTIES:

IMPEDANCE: 75.0 +/- 3.0 Ohms

VELOCITY OF PROPAGATION: 85.0% NOMINAL



ATTENUATION @ 68°F (20°C):­­



  @ Frequency MHz

 dB/100 ft. (MAX.)

  dB/100 meters (MAX.)

          5 MHz

       0.58 dB

           1.90 dB

          55 MHz

1.60 dB

5.25 dB

211 MHz

3.05 dB

10.00 dB

450 MHz

4.40 dB

14.43 dB

550 MHz

4.90 dB

16.08 dB

750 MHz

5.65 dB

18.54 dB

865 MHz

6.10 dB

20.01 dB

1000 MHz

6.55 dB

21.49 dB





               superlink coaxial cable
specs conductor Insulation Shield Jacket impedance
  Nom.Dia Material Nom.Dia(mm) Material AL FOIL Braiding(mm) mm ohm
rg58 0.813 CU/CCS 3 PE AL FOIL 32*0.12AL/BC 5.2 50
rg58 19*0.18 CU/TC 3.7 PE / 48*0.12AL/BC 6.2 75
rg59 0.643 CU/CCS 3.7 PE AL FOIL 48*0.12AL/BC/TC 6.2 75
rg59 0.81 CU/CCS 3.7 PE / 64*0.12AL/BC/TC 6.2 75
rg6 1.02 CU/CCS 4.8 FPE AL FOIL 48*0.12AL/BC/TC 7.2 75
rg6 1.02 CU/CCS 4.8 FPE / 96*0.12AL/BC/TC 7.2 75
rg11 1.63 CU/CCS 7.2 FPE AL FOIL 80*0.12AL/BC/TC 10.5 50
rg11 7*0.404 CU/CCS 7.2 FPE / 192*0.12AL/BC/TC 10.5 50
rg213 7*0.752 CU/CCS 7.2 FPE / 192*0.12AL/BC/TC 10.5 50
rg412 2.23 CU/CCA 9.19 FPE TC 13.08 75
rg500 2.77 CU/CCA 11.43 FPE BC 14.22 75
rg540 3.15 CU/CCA 13.03 FPE TC 15.49 75





ITEMS  DETAILS
MAIN PRODUCTS RG6,RG59,RG11,RG174,fiber optic cable and some LAN cable.
ADVANTAGE LOW price and GOOD quality, cos we can make some raw matierals.
CERTIFICATES CE,UL and ISO9001
MARKET North America,Asia-Pacific,Eroupe,Middle east
CAPACITY 300KM/DAY
MINI ORDER QUALITY 60KM
PAYMENT TERMS T/T,D/P,L/C,D/A
DELIVERY TIME 20DAYS after receiving advance deposit
